30 / 33 page  30 4256B–USB–03/06 AT89C5132 Appendix A Table 17. Summary of Frames from Host Command Identifier data[0] data[1] data[2] data[3] data[4] Description Id_prog_start 01h 00h start_address end_address Init Flash programming Id_display_data 03h 00h start_address end_address Display Flash Data 01h Blank Check in Flash Id_write_command 04h 00h 00h Erase block0 (0K to 8K) 20h Erase block1 (8K to 16K) 40h Erase block2 (16K to 32K) 80h Erase block3 (32K to 64K) FFh Full Chip Erase (bits at FFh) 01h 00h Value Write value in BSB 01h Write value in SBV 05h Write value in SSB 06h Write value in EB 02h 00h Value Write value in Fuse (HSB) 03h 00h Hardware reset 01h address LJMP address Id_read_command 05h 00h 00h Read Bootloader Version 01h Read Device boot ID1 02h Read Device boot ID2 01h 00h Read BSB 01h Read SBV 05h Read SSB 06h Read EB 30h Read Manufacturer Code 31h Read Family Code 60h Read Product Name 61h Read Product Revision 02h 00h Read HWB |
|
