AISC-1210-R15 Datasheet(PDF) 3 Page - Abracon Corporation |
|
|
|||||||||||||||||||||||||||||
AISC-1210-R15 Datasheet(HTML) 3 Page - Abracon Corporation |
|
|
3 / 4 page  ABRACON IS ISO 9001 / QS 9000 CERTIFIED ABRACON IS ISO 9001 / QS 9000 CERTIFIED AISC-1210-xxx 30332 Esperanza, Rancho Santa Margarita, California92688 tel 949-546-8000 | fax 949-546-8001| www.abracon.com Revised: 12.28.12 Visit www.abracon.com for Terms & Conditions of Sale SMD CERAMIC WIRE-WOUND INDUCTORS Pb RoHS Compliant 3.65 x 2.95 x 2.70mm AISC-1210- - Inductance Code Tolerance Code Packaging Please refer to the Table G: ±2% T: 1kpcs/reel J: ±5% K: ±10% PART IDENTIFICATIONS: OUTLINE DIMENSIONS: Dimension: mm Materials A MAX. B MAX. C MAX. D REF. E REF. F REF. H REF. I REF. J REF. 3.65 2.95 2.70 0.51 2.1±0.2 0.5±0.2 3.02 1.02 1.78 No. Components Material A Coating Ultraviolet epoxy resin B Core Ceramic C Wire Polyurethane system enameled copper wire D Electrodes Mo-Mn with Ni and Au plating |
|
|
