AISC-1210-xxx

30332 Esperanza, Rancho Santa Margarita, California92688

Revised: 12.28.12

Visit www.abracon.com for Terms & Conditions of Sale

SMD CERAMIC WIRE-WOUND INDUCTORS

Compliant

3.65 x 2.95 x 2.70mm

REFLOW PROFILE:

•

•

•

•

Max time at max temp: 10sec.

•

Solder paste: Sn/3.0Ag/0.5Cu

•

Allowed Reflow time: 2x max

TAPE & REEL:

T= tape and reel (1,000pcs/reel)

Dimension: mm

A

B

P

K Max

T

2.96±0.2

3.60±0.2

4.0±0.1

2.50±0.3

0.3±0.1

4.0±0.1

Φ1.5(+0.1/ -0)

P

2.0±0.1

A

T

K

5.0 ±0.1

3.0 ±0.1

4.0±0.1

10±1.5

2.45 ±0.2
