FT240X USB 8-BIT FIFO IC Datasheet

Version 1.3

Document No.: FT_000626 Clearance No.:

FTDI# 259

Appendix C - Revision History

Document Title:

USB 8-BIT FIFO IC FT240X

Document Reference No.:

FT_000626

Clearance No.:

FTDI# 259

Product Page:

http://www.ftdichip.com/FT-X.htm

Document Feedback:

Send Feedback

Version 1.0

Initial Datasheet Created

07/02/12

Version 1.1

Replaced VCC_CORE with VCORE

Updated 24 pin SSOP dimensions

22/02/12

Version 1.2

Clarified MTP Reliability in table 5.8

17/04/12

Edited Table 8.1, changed “Load VCP Driver” to

Disabled

Version 1.2

Removed references to LED signals on the CBUS pins

24/09/2012

in table 3.9 as these are not available on the FT240X.

Version 1.3

updated fron t page to clarify 5V tolerant

14/02/2013

Updated TID

Updated US address
