ST3243EB Datasheet(PDF) 5 Page - STMicroelectronics

Part # ST3243EB
Description  Guaranteed 6 V/ms slew rate range
PDF  16 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
Manufacturer  STMICROELECTRONICS [STMicroelectronics]
Direct Link  http://www.st.com
Logo STMICROELECTRONICS - STMicroelectronics

ST3243EB Datasheet(HTML) 5 Page - STMicroelectronics

  ST3243EB Datasheet HTML 1Page - STMicroelectronics ST3243EB Datasheet HTML 2Page - STMicroelectronics ST3243EB Datasheet HTML 3Page - STMicroelectronics ST3243EB Datasheet HTML 4Page - STMicroelectronics ST3243EB Datasheet HTML 5Page - STMicroelectronics ST3243EB Datasheet HTML 6Page - STMicroelectronics ST3243EB Datasheet HTML 7Page - STMicroelectronics ST3243EB Datasheet HTML 8Page - STMicroelectronics ST3243EB Datasheet HTML 9Page - STMicroelectronics Next Button
Zoom Inzoom in Zoom Outzoom out
 5 / 16 page
background image
ST3243EB, ST3243EC
Truth tables
Doc ID 8648 Rev 12
5/16
2
Truth tables
Table 3.
Invalid truth table
RS-232 Signal present at any receiver input
INVALID output
YES
H
NO
L
Table 4.
Output control truth table
Force
ON
Force
OFF
Valid receiver level
Operation status
TOUT
ROUT
R2OUTB
X
0
X
Shutdown (Force OFF)
HIGH Z
HIGH Z
ACTIVE
11
X
Normal operating (Force
ON)
ACTIVE
ACTIVE
ACTIVE
0
1
YES
Normal operating
(Auto power-down)
ACTIVE
ACTIVE
ACTIVE
01
NO
Shutdown
(Auto power-down)
HIGH Z
ACTIVE
ACTIVE
