Compact, Cost-Effective Wafer-Level

Camera Module for Single-Use Endoscopes

OVM6946 400x400productbrief

lead free

available in

a lead-free

package

OmniVision's OVM6946 is a compact camera module for

medical applications such as minimally-invasive

endoscopes. The 1/18-inch OVM6946 utilizes

OmniVision's market-proven CameraCubeChip™ wafer-

level module technology to streamline manufacturing

processes and shorten time-to-market, and is the

industry's most cost-effective single-chip imaging

solution for single-use endoscopes.

Built on OmniVision's OmniBSI+™ pixel architecture, the

OVM6946 captures high quality 400 x 400 resolution

video at 30 frames per second (fps). The OVM6946

comes in a compact 1.05 mm x 1.05 mm package with a

z-height of 2.27 mm, enabling a wide 120-degree field

of view with an extended focusing range of 5 mm to

50 mm. The OVM6946 is well-suited to a wide range of

endoscope applications, including medical, veterinarian,

and industrial.

Find out more at www.ovt.com.
