YB215CWCKW01-5D-JS datasheet(9/13 Pages) NKK

9 / 13 page

Series YB2

Panel Seal Pushbuttons

D126

www.nkkswitches.com

TYPICAL SWITCH DIMENSIONS

Single Pole

Double Pole

YB215CWCKW01-6B-JB

PANEL THICKNESS & CUTOUT

Recommended

Panel Thickness

.020” ~ .197”

(0.5mm ~ 5.0mm)

Side-by-side Mounting

YB216CWSPW01-N-P

Recommended

Panel Thickness

.020” ~ .197”

(0.5mm ~ 5.0mm)

Side-by-side Mounting

(25.0)

.984

(19.0)

.748

Dia

(33.6)

1.323

(7.3)

.288

(1.8)

.071

(2.8)

.110

Typ

(0.5)

.020

Typ

(1.2) x (2.0) Typ

.047 x .079

M16 P1

(7.3)

.288

(3.7)

.146

(9.7)

.382

(6.0)

.236

(11.1)

.437

COM

- +

(33.6)

1.323

(7.3)

.288

(1.8)

.071

M16 P1

(2.8)

.110

Typ

(0.5)

.020

Typ

(1.2) x (2.0) Typ

.047 x .079

(7.3)

.288

(24.0)

.945

(18.0)

.709

(25.4) Min

1.00

(10.5)

Typ

.413

(1.7)

Typ

.067

(22.0)

.866

Dia Typ

+ 0.3

– 0.0

(25.4) Min

1.00

+ 0.1

– 0.0

+ 0.0

– 0.1

(21.0)

Sq Typ

.827

(24.5) Min

.965

+ 0.3

– 0.0

(24.5) Min

.965

Single Pole

Double Pole

(3.7)

.146

(9.7)

.382

(3.0)

.118

(5.55)

.219

COM

- +

(11.1)

.437

(6.0)

.236

(3.7)

.146

(9.7)

.382

COM

(5.55)

.219

(3.0)

.118

(3.7)

.146

COM

(9.7)

.382
