FOR AUTOMOTIVE AUDIO VERTICAL CHIP TYPE ALUMINUM ELECTROLYTIC CAPACITORS[RVM]

RVM-10V331MHA5PUN-R2

Features

Item Summary

330uF±20%, 10V, φ10x10.5mm, SMD

Lifecycle Stage

Mass Production

AEC-Q200 qualified

Standard packaging quantity (minimum)

500

Products characteristics table

Capacitance

330 uF ± 20 %

Rated Voltage

10 V

tanδ (max)

0.24

Operating Temp. Range

-55 to +105 ℃

Leakage current (min)

33 uA at 2 min

Rated Ripple (max)

194 mArms at 120 Hz / 105 ℃

Impedance ratio

2

___[-25℃/+20℃]

Impedance ratio

4

___[-55℃/+20℃]

Endurance

2000 hr at 105 ℃

___[Test time]

Endurance

Within ±30% of initial value

___[Capacitance change]

Endurance

300% or less of initial specified value

___[tanδchange]

Shape

Vertical Chip

(SMD)

Type

Audio

RoHS2 Compliance

Yes

REACH Compliance

Yes

Soldering

Reflow

LeadForming/Taping

Taping Embossed

External Dimensions

Dimension φD

φ10 ±0.5 mm

Dimension L

10.5 ±0.5 mm

Dimension P (F)

Typ 4.7 mm

Dimension C (d)

Typ 3.3 mm
