 3 / 4 page
background image
WBFBP-02C Suggested Pad Layout
Min.
Max.
A
0.450
0.550
0.018
0.022
A1
0.010
0.100
0.000
0.004
D
0.950
1.050
0.037
0.041
E
0.550
0.650
0.022
0.026
D1
E1
b
0.270
0.370
0.011
0.015
b1
0.250
0.350
0.010
0.014
e
0.555
0.655
0.022
0.026
e1
L
0.250
0.350
0.010
0.014
L1
L2
0.370
0.470
0.015
0.019
L3
0.040REF.
0.002REF.
0.420REF.
0.017REF.
0.030REF.
0.001REF.
0.230REF.
0.009REF.
Symbol
Dimensions In Millimeters
Dimensions In Inches
0.019REF.
0.470REF.
WBFBP-02C Package Outline Dimensions
Min.
Max.
2020. 06. 16
3/4
Revision No : 1
FDR54LED02
0.470
0.350
0.150
0.180
0.605
