CC1110-RTY1 Datasheet(PDF) 190 Page - Texas Instruments |
|
|
|||||||||||||||||||||||||||||
CC1110-RTY1 Datasheet(HTML) 190 Page - Texas Instruments |
|
|
190 / 203 page  CC1110 CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A Page 190 of 202 Bit Field Name Reset R/W Description 7:0 FREQOFF_EST R The estimated frequency offset (two’s complement) of the carrier. Resolution is FXTAL/2 14 (1.5kHz-1.7kHz); range is ±186kHz to ±217kHz, dependent of XTAL frequency. Frequency offset compensation is only supported for 2-FSK, GFSK and MSK modulation. This register will read 0 when using ASK or OOK modulation. 0xDF39: LQI – Demodulator estimate for Link Quality Bit Field Name Reset R/W Description 7 CRC OK R The last CRC comparison matched. Cleared when entering/restarting RX mode. 6:0 LQI_EST[6:0] R The Link Quality Indicator estimates how easily a received signal can be demodulated. Calculated over the 64 symbols following the sync word (first 8 packet bytes for 2-ary modulation, first 16 packet bytes for 4-ary modulation). 0xDF3A: RSSI – Received signal strength indication Bit Field Name Reset R/W Description 7:0 RSSI R Received signal strength indicator |
|
