CC1110
CC1110 PRELIMINARY Datasheet (Rev. 1.01) SWRS033A
Page 191 of 202
0xDF3B: MARCSTATE – Main Radio Control State Machine state
Bit
Field Name
Reset
R/W
Description
7:5
Reserved
R0
4:0
MARC_STATE[4:0]
R
Main Radio Control FSM State
Value
State name
State (Figure 38, page
168)
0 (0x00)
SLEEP
SLEEP
1 (0x01)
IDLE
IDLE
2 (0x02)
XOFF
XOFF
3 (0x03)
VCOON_MC
MANCAL
4 (0x04)
REGON_MC
MANCAL
5 (0x05)
MANCAL
MANCAL
6 (0x06)
VCOON
FS_WAKEUP
7 (0x07)
REGON
FS_WAKEUP
8 (0x08)
STARTCAL
CALIBRATE
9 (0x09)
BWBOOST
SETTLING
10 (0x0A)
FS_LOCK
SETTLING
11 (0x0B)
IFADCON
SETTLING
12 (0x0C)
ENDCAL
CALIBRATE
13 (0x0D)
RX
RX
14 (0x0E)
RX_END
RX
15 (0x0F)
RX_RST
RX
16 (0x10)
TXRX_SWITCH
TXRX_SETTLING
17 (0x11)
RX_OVERFLOW
RX_OVERFLOW
18 (0x12)
FSTXON
FSTXON
19 (0x13)
TX
TX
20 (0x14)
TX_END
TX
21 (0x15)
RXTX_SWITCH
RXTX_SETTLING
22 (0x16)
TX_UNDERFLOW
TX_UNDERFLOW
0xDF3C: PKTSTATUS – Current GDOx status and packet status
Bit
Field Name
Reset
R/W
Description
7
CRC_OK
0
R
The last CRC comparison matched. Cleared when
entering/restarting RX mode.
6
CS
0
R
Carrier sense
5
PQT_REACHED
0
R
Preamble Quality reached
4
CCA
0
R
Clear channel assessment
3
SFD
0
R
Start of Frame Delimiter found
2:0
-
000
R0
Not used.
