SERIESONE DR SERIES | DC OUTPUT

DIN RAIL MOUNT SOLID STATE RELAYS

Features

Applications

• Ratings from 3 up to 24 Amps

• Load voltage ratings of 1-60 VDC and 1-100 VDC

• Fits standard 35mm DIN Rail

• LED input status indicator

• DC control

• UL and cUL Listed, CE & RoHS Compliant

• UL 508 Endurance Rating for Enhanced Reliability

• UL Class I and II, Division 2, for Hazardous Locations

• Battery Management Systems

• Backup Power Supplies

• Valve Control

• Lighting control

• Automation Equipment

Sensata | Crydom SeriesOne DR family of DIN Rail mount Solid State Relays incorporate proprietary thermal management technology to achieve exceptional

output ratings of 3 up to 24 Amps at 1 to 100 VDC in compact 11mm and 18mm wide housings.

These compact SSRs are ideal for use in demanding applications where space may be limited, providing greater power density than other DIN Rail Solid State

Relays.

Control Voltage

60V, 3 A

60V, 6 A

60V, 12 A

100V, 3 A

100V, 6 A

100V, 10A

100V, 12A

100V, 24 A

4-32 VDC

DR06D03

DR06D06

DR06D12

DR10D03

DR10D06

DR10D10

DR10D12

DR10D24

PRODUCT SELECTION

3, 6 & 10 Amps

12 & 24 Amps
