PD30ETDR10BPA2IO datasheet(13/19 Pages) CARLOGAVAZZI

13 / 19 page

Carlo Gavazzi Industri A/S

PD30ETDx10BPxxIO - IO-Link

PD30ETDx10BPxxIO ENG

28/04/2021

LED indication

LED indication selection

• LED indication inactive

• LED indication active

• Find my sensor

Factory settings: LED indication active

Environmental

Ambient temperature

-25°... +60°C (-13°... +140°F)

Operating 1)

-40° ... +85°C (-40° ... +185°F)

Storage 1)

Ambient humidity range

35% ... 95%

Operating 2)

35% ... 95%

Storage 2)

Ambient light

≤ 10 000 lux

@ 3000 … 3200 °K

Vibration

10 ...150 Hz, 1.0 mm/15 g

EN 60068-2-6

Shock

30 g

n / 11 ms, 3 pos, 3 neg per axis

EN60068-2-27

Drop test

2 x 1 m and 100 x 0.5 m

EN 60068-2-31

Rated insulation voltage (U

50 VDC

Dielectric insulation voltage

≥ 500 VAC rms

50/60 Hz for 1 min.

Rated impulse withstand voltage

>1 kV (with 500 Ω)

1.2/50 μs

Pollution degree

IEC60664, 60664A; EN60947-1

Overvoltage category

III

IEC60664; EN60947-1

Degree of protection

IP67, IP68 @ 2 m and 20 h

IEC60539; EN60947-1

IP69K

(DIN 40050-9)

NEMA Enclosure Types

1, 2, 4, 4X, 5, 6, 6P, 12

NEMA 250

Do not bend the cable in temperatures below -10°C

With no icing or condensation

EMC

Electrostatic discharge immunity test ± 8 kV @ air discharge or

± 4 kV @ contact discharge

IEC 61000-4-2; EN60947-1

Electromagnetic field immunity

10 V/m

IEC 61000-4-3; EN60947-1

Fast transient immunity

±2 kV / 5 kHz

IEC 61000-4-4; EN60947-1

Wire-conducted noise

10 Vrms

IEC 61000-4-3; EN60947-1

Power frequency magnetic field im-

munity test

Continuous: >30 A/m, 28 µ tesla

Short-time: >300 A/m, 280 µ tesla

IEC 61000-4-8; EN60947-1
