Application functions

Selectable dedicated applications

• No application

• Pattern Recognition

• Speed and Length

• Divider function

• Object and Gap Monitoring

Factory settings: No application

Pattern Recognition

Function description

The Pattern recognition function detects a pattern (e.g. a row of holes or

pins) and compare the order with a pre-teached reference pattern.

Conditions

Two sensors (Main sensor and Trigger sensor) are needed for this function.

Settings

• The Trigger sensor has to detect the full length of the body that contains

the pattern.

• The Main sensor has to be aimed at the e.g. holes or pins that constitute

the pattern.

Speed and Length

Function description

This function is designed to monitor the length of an object as well as the

speed of a conveyour belt. The actual value if the length in [mm] and the

speed in [mm/s] are directly available on the IO-Link master.

Conditions

Two sensors (Main sensor and Trigger sensor) are needed for this function.

Settings

Distance between sensors.

25 ... 150 mm

Factory settings: 100 mm

Divider function

Function description

This function can be used to e.g. monitor how many items that are packed

into a carton box. Once the preset number is reached the sensor gives an

output so the full box can be replaced.

Conditions

Only one sensor is needed for this function.

Settings

A counter value must be set in the sensor.

Counter limit.

1...60 000

Factory settings: 5
