STPR620CT Datasheet(PDF) 1 Page - STMicroelectronics |
|
|
|||||||||||||||||||||||||||||
STPR620CT Datasheet(HTML) 1 Page - STMicroelectronics |
|
|
1 / 6 page  STPR620CT STPR620CF ® October 1999- Ed:2A ULTRA FAST RECOVERY RECTIFIER DIODES ISOWATT220AB (Plastic) STPR620CF SUITED FOR SMPS LOW LOSSES LOW FORWARD AND REVERSE RECOVERY TIME HIGH SURGE CURRENT CAPABILITY HIGH AVALANCHE ENERGY CAPABILITY FEATURES ABSOLUTE MAXIMUM (limiting values) Symbol Parameter Value Unit VRRM Repetitive peak reverse voltage 200 V IF(RMS) RMS forward current Per diode 10 A IF(AV) Average forward current δ = 0.5 TO220AB Tc=125 °C Per diode 3A ISOWATT220AB Tc=120 °C Per device 6 IFSM Surge non repetitive forward current tp=10ms sinusoidal Per diode 30 A Tstg Tj Storage temperature range Maximum junction temperature - 65 to + 150 - 65 to + 150 °C °C K A1 A2 A1 K A2 TO220AB (Plastic) STPR620CT K A1 A2 Low cost dual center tap rectifier suited for switch- mode power supply and high frequency DC to DC converters. Packaged in TO220AB and ISOWATT220AB, this device is intended for use in low voltage, high fre- quency inverters, free wheeling and polarity pro- tection applications. DESCRIPTION 1/6 |
