1068 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1016 of 1102 REJ09B0294-0100 Register Abbreviation Bit 31/23/15/7 Bit 30/22/14/6 Bit 29/21/13/5 Bit 28/20/12/4 Bit 27/19/11/3 Bit 26/18/10/2 Bit 25/17/9/1 Bit 24/16/8/0 Module ASTCR AST7 AST6 AST5 AST4 AST3 AST2 AST1 AST0 BSC — — — — — — — — WTCRA — W72 W71 W70 — W62 W61 W60 — W52 W51 W50 — W42 W41 W40 WTCRB — W32 W31 W30 — W22 W21 W20 — W12 W11 W10 — W02 W01 W00 RDNCR RDN7 RDN6 RDN5 RDN4 RDN3 RDN2 RDN1 RDN0 — — — — — — — — CSACR CSXH7 CSXH6 CSXH5 CSXH4 CSXH3 CSXH2 CSXH1 CSXH0 CSXT7 CSXT6 CSXT5 CSXT4 CSXT3 CSXT2 CSXT1 CSXT0 IDLCR IDLS3 IDLS2 IDLS1 IDLS0 IDLCB1 IDLCB0 IDLCA1 IDLCA0 IDLSEL7 IDLSEL6 IDLSEL5 IDLSEL4 IDLSEL3 IDLSEL2 IDLSEL1 IDLSEL0 BCR1 BRLE BREQOE — — — — WDBE WAITE DKC — — — — — — — BCR2 — — — IBCCS — — — PWDBE ENDIANCR LE7 LE6 LE5 LE4 LE3 LE2 — — SRAMCR BCSEL7 BCSEL6 BCSEL5 BCSEL4 BCSEL3 BCSEL2 BCSEL1 BCSEL0 — — — — — — — — BROMCR BSRM0 BSTS02 BSTS01 BSTS00 — — BSWD01 BSWD00 BSRM1 BSTS12 BSTS11 BSTS10 — — BSWD11 BSWD10 MPXCR MPXE7 MPXE6 MPXE5 MPXE4 MPXE3 — — — — — — — — — — ADDEX DRAMCR DRAME DTYPE — — OEE RAST — CAST BE RCDM DDS — — — MXC1 MXC0 DRACCR — — TPC1 TPC0 — — RCD1 RCD0 — — — — — — — — SDCR MRSE — — — — — — — CKSPE — — — — — — TRWL REFCR CMF CMIE RCW1 RCW0 — RTCK2 RTCK1 RTCK0 RFSHE RLW2 RLW1 RLW0 SLFRF TPCS2 TPCS1 TPCS0 RTCNT RTCOR RAMER — — — — RAMS RAM2 RAM1 RAM0 |
|
