1071 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1019 of 1102 REJ09B0294-0100 Register Abbreviation Bit 31/23/15/7 Bit 30/22/14/6 Bit 29/21/13/5 Bit 28/20/12/4 Bit 27/19/11/3 Bit 26/18/10/2 Bit 25/17/9/1 Bit 24/16/8/0 Module TCR_5 — CCLR1 CCLR0 CKEG1 CKEG0 TPSC2 TPSC1 TPSC0 TPU_5 TMDR_5 — — — — MD3 MD2 MD1 MD0 TIOR_5 IOB3 IOB2 IOB1 IOB0 IOA3 IOA2 IOA1 IOA0 TIER_5 TTGE — TCIEU TCIEV — — TGIEB TGIEA TSR_5 TCFD — TCFU TCFV — — TGFB TGFA TCNT_5 TGRA_5 TGRB_5 DTCERA DTCEA15 DTCEA14 DTCEA13 DTCEA12 DTCEA11 DTCEA10 DTCEA9 DTCEA8 INTC DTCEA7 DTCEA6 DTCEA5 DTCEA4 — — — — DTCERB DTCEB15 — DTCEB13 DTCEB12 DTCEB11 DTCEB10 DTCEB9 DTCEB8 DTCEB7 DTCEB6 DTCEB5 DTCEB4 DTCEB3 DTCEB2 DTCEB1 DTCEB0 DTCERC DTCEC15 DTCEC14 DTCEC13 DTCEC12 DTCEC11 DTCEC10 DTCEC9 DTCEC8 DTCEC7 DTCEC6 DTCEC5 DTCEC4 DTCEC3 DTCEC2 — — DTCERD — — DTCED13 DTCED12 DTCED11 DTCED10 — — — — DTCED5 DTCED4 DTCED3 DTCED2 DTCED1 DTCED0 DTCERE — — DTCEE13 DTCEE12 — — — — — — — — — — — — DTCERG — — — — DTCEG11 DTCEG10 — — DTCEG7 DTCEG6 — — — — — — DTCERH DTCEH15 DTCEH14 — — — — — — — — — — — — — — DTCCR — — — RRS RCHNE — — ERR INTCR — — INTM1 INTM0 NMIEG — — — CPUPCR CPUPCE DTCP2 DTCP1 DTCP0 IPSETE CPUP2 CPUP1 CPUP0 IER IRQ15E — — — IRQ11E IRQ10E IRQ9E IRQ8E IRQ7E IRQ6E IRQ5E IRQ4E IRQ3E IRQ2E IRQ1E IRQ0E ISR IRQ15F — — — IRQ11F IRQ10F IRQ9F IRQ8F IRQ7F IRQ6F IRQ5F IRQ4F IRQ3F IRQ2F IRQ1F IRQ0F |
|
