H8SX/1663 Datasheet(PDF) 1069 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1069 Page - Renesas Technology Corp |
|
|
1069 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1017 of 1102 REJ09B0294-0100 Register Abbreviation Bit 31/23/15/7 Bit 30/22/14/6 Bit 29/21/13/5 Bit 28/20/12/4 Bit 27/19/11/3 Bit 26/18/10/2 Bit 25/17/9/1 Bit 24/16/8/0 Module MDCR MDS7 — — — MDS3 MDS2 MDS1 MDS0 SYSTEM — — — — — — — — SYSCR — — MACS — FETCHMD — EXPE RAME — — — — — — DTCMD — SCKCR PSTOP1 PSTOP0 — — — ICK2 ICK1 ICK0 — PCK2 PCK1 PCK0 — BCK2 BCK1 BCK0 SBYCR SSBY OPE — STS4 STS3 STS2 STS1 STS0 SLPIE — — — — — — — MSTPCRA ACSE MSTPA14 MSTPA13 MSTPA12 MSTPA11 MSTPA10 MSTPA9 MSTPA8 MSTPA7 MSTPA6 MSTPA5 MSTPA4 MSTPA3 MSTPA2 MSTPA1 MSTPA0 MSTPCRB MSTPB15 MSTPB14 MSTPB13 MSTPB12 MSTPB11 MSTPB10 MSTPB9 MSTPB8 MSTPB7 MSTPB6 MSTPB5 MSTPB4 MSTPB3 MSTPB2 MSTPB1 MSTPB0 MSTPCRC MSTPC15 MSTPC14 MSTPC13 MSTPC12 MSTPC11 MSTPC10 MSTPC9 MSTPC8 MSTPC7 MSTPC6 MSTPC5 MSTPC4 MSTPC3 MSTPC2 MSTPC1 MSTPC0 SUBCKCR — — — — — EXSTP WAKE32K CS32K SEMR_2 — — — — ABCS ACS2 ACS1 ACS0 SCI_2 SMR_4* C/ A (GM) CHR (BLK) PE (PE) O/ E (O/ E) STOP (BCP1) MP (BCP0) CKS1 CKS0 SCI_4 BRR_4 SCR_4* TIE RIE TE RE MPIE TEIE CKE1 CKE0 TDR_4 SSR_4* TDRE RDRF ORER FER (ERS) PER TEND MPB MPBT RDR_4 SCMR_4 — — — — SDIR SINV — SMIF FCCS — — — FLER — — — SCO FLASH FPCS — — — — — — — PPVS FECS — — — — — — — EPVB FKEY K7 K6 K5 K4 K3 K2 K1 K0 FTDAR TDER TDA6 TDA5 TDA4 TDA3 TDA2 TDA1 TDA0 ICCRA_0 ICE RCVD MST TRS CKS3 CKS2 CKS1 CKS0 IIC2_0 ICCRB_0 BBSY SCP SDAO — SCLO — IICRST — ICMR_0 — WAIT — — BCWP BC2 BC1 BC0 ICIER_0 TIE TEIE RIE NAKIE STIE ACKE ACKBR ACKBT ICSR_0 TDRE TEND RDRF NACKF STOP AL AAS ADZ SAR_0 SVA6 SVA5 SVA4 SVA3 SVA2 SVA1 SVA0 — |
|
