 1103 / 1158 page
background image
Section 25 Electrical Characteristics
Rev.1.00 Jun. 07, 2006 Page 1051 of 1102
REJ09B0294-0100
Item
Symbol
Min.
Max.
Unit
Test
Conditions
Precharge time 1 for self-refresh
t
RPS1
2.5
× t
cyc – 20
ns
Figure 25.28
Precharge time 2 for self refresh
t
RPS2
3.0
× t
cyc – 20
ns
Figure 25.27
Address delay time 2
t
AD2
1
18
ns
CS delay time 4
t
CSD4
1
15
ns
Figures 25.29
to 25.32
DQM delay time
t
DQMD
1
15
ns
CKE delay time
t
CKED
1
15
ns
Table 25.6
Bus Timing (4)
Conditions: V
CC = PLLVCC = DrVCC = 3.0 V to 3.6 V, AVCC = 3.0 V to 3.6 V, Vref = 3.0 V to AVCC,
V
SS = PLLVSS = DrVSS = AVSS = 0 V, Bφ = 8 MHz to 50 MHz,
T
a = –20°C to +75°C (regular specifications),
T
a = –40°C to +85°C (wide-range specifications)
Item
Symbol
Min.
Max.
Unit
Test
Conditions
Read data setup time 3
t
RDS3
12
ns
Read data hold time 3
t
RDH3
0
ns
Figures 25.29
to 25.32
Read data setup time 4
t
RDS4
12
ns
Read data hold time 4
t
RDH4
0
ns
Write data delay time 2
t
WDD2
15
ns
Write data hold time 4
t
WDH4
1
ns
