H8SX/1663 Datasheet(PDF) 1100 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1100 Page - Renesas Technology Corp |
|
|
1100 / 1158 page  Section 25 Electrical Characteristics Rev.1.00 Jun. 07, 2006 Page 1048 of 1102 REJ09B0294-0100 Item Symbol Min. Max. Unit Test Conditions CS delay time 1 t CSD1 15 ns AS delay time t ASD 15 ns RD delay time 1 t RSD1 1.0 15 ns RD delay time 2 t RSD2 15 ns Read data setup time 1 t RDS1 15 ns Read data setup time 2 t RDS2 15 ns Figures 25.8 to 25.34 Read data hold time 1 t RDH1 1.0 ns Read data hold time 2 t RDH2 0 ns Read data access time 2 t AC2 1.5 × t cyc – 30 ns Read data access time 4 t AC4 2.5 × t cyc – 30 ns Read data access time 5 t AC5 1.0 × t cyc – 30 ns Read data access time 6 t AC6 2.0 × t cyc – 30 ns Read data access time (from address) 1 t AA1 1.0 × t cyc – 30 ns Read data access time (from address) 2 t AA2 1.5 × t cyc – 30 ns Read data access time (from address) 3 t AA3 2.0 × t cyc – 30 ns Read data access time (from address) 4 t AA4 2.5 × t cyc – 30 ns Read data access time (from address) 5 t AA5 3.0 × t cyc – 30 ns |
|
