Section 19 Serial Communication Interface (SCI, IrDA, CRC)
Rev. 2.00 Sep. 24, 2008 Page 951 of 1468
REJ09B0412-0200
Table 19.15 SCI Interrupt Sources (SCI_5 and SCI_6)
Name
Interrupt Source
Interrupt Flag
DTC Activation
DMAC Activation
Priority
RXI
Receive data full
RDRF
Not possible
Possible
High
TXI
Transmit data empty TDRE
Not possible
Possible
ERI
Receive error
ORER, FER, or PER
Not possible
Not possible
TEI
Transmit end
TEND
Not possible
Not possible
Low
19.9.2
Interrupts in Smart Card Interface Mode
Table 19.16 shows the interrupt sources in smart card interface mode. A transmit end (TEI)
interrupt request cannot be used in this mode.
Note that the priority order for interrupts is different between the group of SCI_0, 1, 2, and 4 and
the group of SCI_5 and SCI_6.
Table 19.16 SCI Interrupt Sources (SCI_0, 1, 2, and 4)
Name
Interrupt Source
Interrupt Flag
DTC Activation
DMAC Activation
Priority
ERI
Receive error or error
signal detection
ORER, PER, or ERS
Not possible
Not possible
High
RXI
Receive data full
RDRF
Possible
Possible
TXI
Transmit data empty
TEND
Possible
Possible
Low
Table 19.17 SCI Interrupt Sources (SCI_5 and SCI_6)
Name
Interrupt Source
Interrupt Flag
DTC Activation
DMAC Activation
Priority
RXI
Receive data full
RDRF
Not possible
Possible
High
TXI
Transmit data empty
TDRE
Not possible
Possible
ERI
Receive error or error
signal detection
ORER, PER, or ERS
Not possible
Not possible
Low
