Section 29 List of Registers

Rev. 2.00 Sep. 24, 2008 Page 1302 of 1468

REJ09B0412-0200

Abbreviation

Number

of Bits

Address

Module

Data

Width

Access

Cycles

(Read/Write)

DTC enable register B

DTCERB

H'FFF22

INTC

φ/3Iφ

DTC enable register C

DTCERC

H'FFF24

INTC

φ/3Iφ

DTC enable register D

DTCERD

H'FFF26

INTC

φ/3Iφ

DTC enable register E

DTCERE

H'FFF28

INTC

φ/3Iφ

DTC enable register F

DTCERF

H'FFF2A

INTC

φ/3Iφ

DTC control register

DTCCR

H'FFF30

INTC

φ/3Iφ

Interrupt control register

INTCR

H'FFF32

INTC

φ/3Iφ

CPU priority control register

CPUPCR

H'FFF33

INTC

φ/3Iφ

IRQ enable register

IER

H'FFF34

INTC

φ/3Iφ

IRQ status register

ISR

H'FFF36

INTC

φ/3Iφ

Port 1 register

PORT1

H'FFF40

I/O port

φ/-

Port 2 register

PORT2

H'FFF41

I/O port

φ/-

Port 3 register

PORT3

H'FFF42

I/O port

φ/-

Port 5 register

PORT5

H'FFF44

I/O port

φ/-

Port 6 register

PORT6

H'FFF45

I/O port

φ/-

Port A register

PORTA

H'FFF49

I/O port

φ/-

Port B register

PORTB

H'FFF4A

I/O port

φ/-

Port C register

PORTC

H'FFF4B

I/O port

φ/-

Port D register

PORTD

H'FFF4C

I/O port

φ/-

Port E register

PORTE

H'FFF4D

I/O port

φ/-

Port F register

PORTF

H'FFF4E

I/O port

φ/-

Port 1 data register

P1DR

H'FFF50

I/O port

φ/2Pφ

Port 2 data register

P2DR

H'FFF51

I/O port

φ/2Pφ

Port 3 data register

P3DR

H'FFF52

I/O port

φ/2Pφ

Port 6 data register

P6DR

H'FFF55

I/O port

φ/2Pφ

Port A data register

PADR

H'FFF59

I/O port

φ/2Pφ

Port B data register

PBDR

H'FFF5A

I/O port

φ/2Pφ

Port C data register

PCDR

H'FFF5B

I/O port

φ/2Pφ

Port D data register

PDDR

H'FFF5C

I/O port

φ/2Pφ

Port E data register

PEDR

H'FFF5D

I/O port

φ/2Pφ

Port F data register

PFDR

H'FFF5E

I/O port

φ/2Pφ
