H8SX/1663R Datasheet(PDF) 1336 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1336 Page - Renesas Technology Corp |
|
|
1336 / 1504 page  Section 29 List of Registers Rev. 2.00 Sep. 24, 2008 Page 1304 of 1468 REJ09B0412-0200 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Serial status register_1 SSR_1 8 H'FFF8C SCI_1 8 2P φ/2Pφ Receive data register_1 RDR_1 8 H'FFF8D SCI_1 8 2P φ/2Pφ Smart card mode register_1 SCMR_1 8 H'FFF8E SCI_1 8 2P φ/2Pφ A/D data register A_0 ADDRA_0 16 H'FFF90 A/D_0 16 2P φ/2Pφ A/D data register B_0 ADDRB_0 16 H'FFF92 A/D_0 16 2P φ/2Pφ A/D data register C_0 ADDRC_0 16 H'FFF94 A/D_0 16 2P φ/2Pφ A/D data register D_0 ADDRD_0 16 H'FFF96 A/D_0 16 2P φ/2Pφ A/D data register E_0 ADDRE_0 16 H'FFF98 A/D_0 16 2P φ/2Pφ A/D data register F_0 ADDRF_0 16 H'FFF9A A/D_0 16 2P φ/2Pφ A/D data register G_0 ADDRG_0 16 H'FFF9C A/D_0 16 2P φ/2Pφ A/D data register H_0 ADDRH_0 16 H'FFF9E A/D_0 16 2P φ/2Pφ A/D control/status register_0 ADCSR_0 8 H'FFFA0 A/D_0 16 2P φ/2Pφ A/D control register_0 ADCR_0 8 H'FFFA1 A/D_0 16 2P φ/2Pφ Timer control/status register TCSR 8 H'FFFA4 WDT 16 2P φ/3Pφ Timer counter TCNT 8 H'FFFA5 WDT 16 2P φ/3Pφ Reset control/status register RSTCSR 8 H'FFFA7 WDT 16 2P φ/3Pφ Timer control register_0 TCR_0 8 H'FFFB0 TMR_0 16 2P φ/2Pφ Timer control register_1 TCR_1 8 H'FFFB1 TMR_1 16 2P φ/2Pφ Timer control/status register_0 TCSR_0 8 H'FFFB2 TMR_0 16 2P φ/2Pφ Timer control/status register_1 TCSR_1 8 H'FFFB3 TMR_1 16 2P φ/2Pφ Time constant register A_0 TCORA_0 8 H'FFFB4 TMR_0 16 2P φ/2Pφ Time constant register A_1 TCORA_1 8 H'FFFB5 TMR_1 16 2P φ/2Pφ Time constant register B_0 TCORB_0 8 H'FFFB6 TMR_0 16 2P φ/2Pφ Time constant register B_1 TCORB_1 8 H'FFFB7 TMR_1 16 2P φ/2Pφ Timer counter_0 TCNT_0 8 H'FFFB8 TMR_0 16 2P φ/2Pφ Timer counter_1 TCNT_1 8 H'FFFB9 TMR_1 16 2P φ/2Pφ Timer counter control register_0 TCCR_0 8 H'FFFBA TMR_0 16 2P φ/2Pφ Timer counter control register_1 TCCR_1 8 H'FFFBB TMR_1 16 2P φ/2Pφ Timer start register TSTR 8 H'FFFBC TPU 16 2P φ/2Pφ Timer synchronous register TSYR 8 H'FFFBD TPU 16 2P φ/2Pφ Timer control register_0 TCR_0 8 H'FFFC0 TPU_0 16 2P φ/2Pφ |
|
