Section 20 USB Function Module (USB)

Rev. 2.00 Sep. 24, 2008 Page 976 of 1468

REJ09B0412-0200

20.3.7

Interrupt Enable Register 0 (IER0)

IER0 enables the interrupt requests of interrupt flag register 0 (IFR0). When an interrupt flag is set

to 1 while the corresponding bit of each interrupt is set to 1, an interrupt request is sent to the

CPU. The interrupt vector number is determined by the contents of interrupt select register 0

(ISR0).

Bit

Bit Name

Initial Value

R/W

BRST

R/W

EP1 FULL

R/W

EP2 TR

R/W

EP2 EMPTY

R/W

SETUP TS

R/W

EP0o TS

R/W

EP0i TR

R/W

EP0i TS

R/W

Bit

Bit Name

Initial

Value

R/W

Description

BRST

R/W

Bus Reset

EP1 FULL

R/W

EP1 FIFO Full

EP2 TR

R/W

EP2 Transfer Request

EP2 EMPTY

R/W

EP2 FIFO Empty

SETUP TS

R/W

Setup Command Receive Complete

EP0o TS

R/W

EP0o Receive Complete

EP0i TR

R/W

EP0i Transfer Request

EP0i TS

R/W

EP0i Transmission Complete
