H8SX/1663M Datasheet(PDF) 1330 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663M Datasheet(HTML) 1330 Page - Renesas Technology Corp |
|
|
1330 / 1504 page  Section 29 List of Registers Rev. 2.00 Sep. 24, 2008 Page 1298 of 1468 REJ09B0412-0200 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Cluster buffer register 2 CLSBR2 32 H'FFD08 EXDMAC 16 2I φ/2Iφ Cluster buffer register 3 CLSBR3 32 H'FFD0C EXDMAC 16 2I φ/2Iφ Cluster buffer register 4 CLSBR4 32 H'FFD10 EXDMAC 16 2I φ/2Iφ Cluster buffer register 5 CLSBR5 32 H'FFD14 EXDMAC 16 2I φ/2Iφ Cluster buffer register 6 CLSBR6 32 H'FFD18 EXDMAC 16 2I φ/2Iφ Cluster buffer register 7 CLSBR7 32 H'FFD1C EXDMAC 16 2I φ/2Iφ DMA module request select register_0 DMRSR_0 8 H'FFD20 DMAC_0 16 2I φ/2Iφ DMA module request select register_1 DMRSR_1 8 H'FFD21 DMAC_1 16 2I φ/2Iφ DMA module request select register_2 DMRSR_2 8 H'FFD22 DMAC_2 16 2I φ/2Iφ DMA module request select register_3 DMRSR_3 8 H'FFD23 DMAC_3 16 2I φ/2Iφ Interrupt priority register A IPRA 16 H'FFD40 INTC 16 2I φ/3Iφ Interrupt priority register B IPRB 16 H'FFD42 INTC 16 2I φ/3Iφ Interrupt priority register C IPRC 16 H'FFD44 INTC 16 2I φ/3Iφ Interrupt priority register D IPRD 16 H'FFD46 INTC 16 2I φ/3Iφ Interrupt priority register E IPRE 16 H'FFD48 INTC 16 2I φ/3Iφ Interrupt priority register F IPRF 16 H'FFD4A INTC 16 2I φ/3Iφ Interrupt priority register G IPRG 16 H'FFD4C INTC 16 2I φ/3Iφ Interrupt priority register H IPRH 16 H'FFD4E INTC 16 2I φ/3Iφ Interrupt priority register I IPRI 16 H'FFD50 INTC 16 2I φ/3Iφ Interrupt priority register J IPRJ 16 H'FFD52 INTC 16 2I φ/3Iφ Interrupt priority register K IPRK 16 H'FFD54 INTC 16 2I φ/3Iφ Interrupt priority register L IPRL 16 H'FFD56 INTC 16 2I φ/3Iφ Interrupt priority register M IPRM 16 H'FFD58 INTC 16 2I φ/3Iφ Interrupt priority register N IPRN 16 H'FFD5A INTC 16 2I φ/3Iφ Interrupt priority register O IPRO 16 H'FFD5C INTC 16 2I φ/3Iφ Interrupt priority register Q IPRQ 16 H'FFD60 INTC 16 2I φ/3Iφ Interrupt priority register R IPRR 16 H'FFD62 INTC 16 2I φ/3Iφ IRQ sense control register H ISCRH 16 H'FFD68 INTC 16 2I φ/3Iφ IRQ sense control register L ISCRL 16 H'FFD6A INTC 16 2I φ/3Iφ DTC vector base register DTCVBR 32 H'FFD80 BSC 16 2I φ/3Iφ Bus width control register ABWCR 16 H'FFD84 BSC 16 2I φ/3Iφ |
|
