AD9739

Data Sheet

Rev. B | Page 16 of 48

VBW 300kHz

SPAN 53.84MHz

SWEEP 174.6ms (601pts)

CENTER 2.807GHz

#RES BW 30kHz

RMS RESULTS

CARRIER POWER

–24.4dBm/

3.84MHz

FREQ

OFFSET

(MHz)

REF

(MHz)

3.84

(dBc)

–64.90

–66.27

–68.44

–70.20

–70.85

(dBm)

–89.30

–90.67

–92.84

–94.60

–95.25

LOWER

(dBc)

–63.82

–65.70

–66.55

–68.95

–70.45

(dBm)

–88.22

–90.10

–90.95

–93.35

–94.85

UPPER

Figure 31. Typical Single-Carrier WCDMA ACLR Performance at 2.8 GHz,

fDAC = 2457.6 MSPS (Third Nyquist Zone)

VBW 300kHz

SPAN 63.84MHz

SWEEP 207ms (601pts)

CENTER 2.09758GHz

#RES BW 30kHz

RMS RESULTS

CARRIER POWER

–25.53dBm/

3.84MHz

FREQ

OFFSET

(MHz)

REF

(MHz)

3.84

(dBc)

0.22

–66.68

–68.01

–68.61

–68.87

–69.21

(dBm)

–25.31

–92.21

–93.53

–94.14

–94.40

–94.74

LOWER

(dBc)

0.24

0.14

–66.82

–67.83

–67.64

–68.50

(dBm)

–25.29

–25.38

–92.35

–93.36

–93.17

–94.03

UPPER

Figure 32. Typical Four-Carrier WCDMA ACLR Performance at 2.1 GHz,

fDAC = 2457.6 MSPS (Second Nyquist Zone)

VBW 300kHz

SPAN 63.84MHz

SWEEP 207ms (601pts)

CENTER 2.81271GHz

#RES BW 30kHz

RMS RESULTS

CARRIER POWER

–27.98dBm/

3.84MHz

FREQ

OFFSET

(MHz)

REF

(MHz)

3.84

(dBc)

–0.42

–64.32

–66.03

–66.27

–66.82

–67.16

(dBm)

–28.40

–92.30

–94.01

–94.24

–94.79

–95.13

LOWER

(dBc)

–0.10

–0.08

–65.37

–66.06

–63.36

–66.54

(dBm)

–28.07

–28.06

–93.34

–94.03

–93.34

–94.51

UPPER

Figure 33. Typical Four-Carrier WCDMA ACLR Performance at 2.8 GHz,

fDAC = 2457.6 MSPS (Third Nyquist Zone)
