770-001

Shrink Boot

Heat Shrink Molded Part

APPLICATION NOTES

1. Material: Fluid resistant elastomer - Glenair Material Type 1.

3. Sizes 00 to 02 do not contain eyelet.

TABLE I: STRAIGHT BOOT DIMENSIONS, BOOT AND SHELL SIZE

Boot

Size

Shell

Size

Ae Dia

Min

Ce Dia

Min

Ar Dia

Max

at

±30%

Cr Dia

Max

ct

±20%

CO

Ref

PO

±10%

P1

±10%

RO

Ref

00

5

.354 (9.0)

.354 (9.0)

.217 (5.5) .039 (1.0) .079 (2.0)

.028 (0.7)

.295 (7.5) .984 (25.0)

N/A

.551 (14.0)

01

5, 6

.472 (12.0) .472 (12.0) .276 (7.0) .043 (1.1) .118 (3.0)

.028 (0.7)

.295 (7.5) .984 (25.0)

N/A

.551 (14.0)

02

6, 7

.669 (17.0) .669 (17.0) .276 (7.0) .051 (1.3) .138 (3.5)

.028 (0.7) .395 (10.0) 1.181 (30.0)

N/A

.728 (18.5)

03

8, 10

.945 (24.0) .945 (24.0) .413 (10.5) .063 (1.6) .197 (5.5)

.035 (0.9) .395 (10.0) 1.496 (38.0) 1.024 (26.0) .748 (19.0)

04

11-16

1.181 (30.0) 1.181 (30.0) .551 (14.0) .071 (1.8) .236 (6.0)

.039 (1.0) .630 (16.0) 2.165 (55.0) 1.693 (43.0) 1.181 (30.0)

05

16-17

1.260 (32.0) 1.260 (32.0) .709 (18.0) .071 (1.8) .276 (7.0)

.047 (1.2) .748 (19.0) 2.638 (67.0) 1.850 (47.0) 1.299 (33.0)

06

17-21

1.417 (36.0) 1.417 (36.0) .886 (22.0) .079 (2.0) .335 (8.5)

.047 (1.2) .787 (20.0) 3.150 (80.0) 2.362 (60.0) 1.575 (40.0)

07

21-23

1.693 (43.0) 1.693 (43.0) 1.102 (28.0) .087 (2.2) .394 (10.0) .051 (1.3) 1.142 (29.0) 3.898 (99.0) 3.150 (80.0) 2.165 (55.0)

08

25

2.362 (60.0) 2.362 (60.0) 1.378 (35.0) .130 (3.3) .591 (15.0) .063 (1.6) 1.575 (40.0) 5.118 (130.0) 4.331 (110.0) 1.969 (50.0)

Basic Part Number

Product Series

Part Size

(See Table I)

A 1 00 W1

Angular

Function

Material

Oil Resistant and Flame Retardant

Adhesive Lined

(Omit for No Adhesive)

Ø.079 (2.0) Ref

(See Note 3)

Ct

Ct

Recovered (-001)

Recovered (-002)

As Supplied

As Supplied

Ce

Ae

Ce

Ae

P0

R0

Cr

C0

Ar

At

Cr

C0

P1

Ar

At

S - Straight

Shrink Boot
