Printed in U.S.A.

www.glenair.com

CAGE CODE 06324

© 2010 Glenair, Inc.

E-Mail: sales@glenair.com

H-6

H

770-001

90° Shrink Boot

Heat Shrink Molded Part

Ø.079 (2.0) Ref

R

At

Ar

P

C0

Ct

Cr

As Supplied

Ce

Ae

Size 03 To 08

Recovered

TABLE I: 90° BOOT DIMENSIONS, BOOT AND SHELL SIZE

Boot

Size

Shell

Size

Ae Dia

Min

Ce Dia

Min

Ar Dia

Max

at

±30%

Cr Dia

Max

ct

±20%

CO

Ref

P

±20%

R

Ref

03

9

.945 (24.0) .945 (24.0) .394 (10.0) .063 (1.6) .197 (5.0)

.035 (0.9) .394 (10.0) .984 (25.0) .984 (25.0)

04

11-15

1.181 (30.0) 1.181 (30.0) .532 (13.5) .071 (1.8) .217 (5.5)

.039 (1.0) .472 (12.0) 1.260 (32.0) 1.063 (27.0)

05

13-17

1.260 (32.0) 1.260 (32.0) .709 (18.0) .071 (1.8) .276 (7.0)

.047 (1.2) .591 (15.0) 1.535 (39.0) 1.260 (32.0)

06

17-21

1.417 (36.0) 1.417 (36.0) .886 (22.0) .079 (2.0) .335 (8.5)

.047 (1.2) .630 (16.0) 1.929 (49.0) 1.496 (38.0)

07

21-23

1.693 (43.0) 1.693 (43.0) 1.102 (28.0) .087 (2.2) .394 (10.0) .059 (1.5) .709 (18.0) 2.165 (55.0) 1.850 (47.0)

08

23-25

2.165 (55.0) 2.165 (55.0) 1.378 (35.0) .130 (3.3) .591 (15.0) .079 (2.0) 1.260 (32.0) 3.150 (80.0) 2.165 (55.0)

A - 90°

Shrink Boot
