Maximum ratings
STPMS2
8/36
DocID16525 Rev 5
4
Maximum ratings
Table 3: Absolute maximum ratings
Symbol
Parameter
Value
Unit
VCC
DC input voltage
- 0.3 to 6
V
IPIN
Current on any pin (sink/source)
±150
mA
VID
Input voltage on any pin
-0.3 to VCC +0.3
V
VIA
Input voltage at analog pins
(VIP, VIN, IIP, IIN)
-0.7 to 0.7
V
ESD
Human body model
±2
kV
TOP
Operating ambient temperature
- 40 to 85
°C
TJ
Maximum operating junction
temperature
-40 to150
°C
TSTG
Storage temperature
-55 to 150
°C
Absolute maximum ratings are those values beyond which damage to the device
may occur. Functional operation under these conditions is not implied.
Table 4: Thermal data
Symbol
Parameter
Value
Unit
RthJA(1)
Thermal resistance junction-ambient
38.66
°C/W
Notes:
(1)This value is referred to single-layer PCB, JEDEC standard test board.
