ADAR2004
Data Sheet
Rev. 0 | Page 24 of 37
BIAS POINTS AND VOLTAGES
Table 9. Default Bias Points
Register Address
Register Name
Bit Field Name(s)
Register Bit(s)
Default Value
Description
0x011
BIAS_CURRENT_MULT1
0x55
Low and mid band multiplier
bias current
MULT_LOW_BIAS
[3:0]
0x5
Low band multiplier bias current
MULT_MID_BIAS
[7:4]
0x5
Mid band multiplier bias current
0x012
BIAS_CURRENT_MULT2
0x07
High band multiplier bias
current
MULT_HIGH_BIAS
[3:0]
0x7
High band multiplier bias
current
0x013
BIAS_CURRENT_LOAMP
0x78
LO buffer amplifier bias
current
LO_AMP1_BIAS
[3:0]
0x08
LO buffer input stage bias
current
LO_AMP2_BIAS
[7:4]
0x07
LO buffer output stage bias
current
0x014
BIAS_CURRENT_SPLT
0x7A
Active splitter bias current
SPLT1_BIAS
[3:0]
0xA
First stage active splitter bias
current
SPLT2_BIAS
[7:4]
0x7
Second stage active splitter
bias current
0x015
BIAS_CURRENT_LNAMIX
0x2A
LNA and mixer bias current
LNA_BIAS
[3:0]
0xA
LNA bias current
MIX_BIAS
[7:4]
0x2
Mixer bias current
0x016
BIAS_CURRENT_IFAMP
0xC0
IF amplifier bias current
IFAMP_BIAS
[7:4]
0xC
IF amplifier bias current
0x017
IFAMP_CM
0x04
IF amplifier output
common-mode voltage
IFAMP_CM
[3:0]
0x4
IF amplifier output common-
mode voltage
