Data Sheet
ADAR2004
Rev. 0 | Page 29 of 37
Address Name
Bits Bit Name
Description
Reset Access
0x04B
RX_GAIN34_MODE_3
7
RESERVED
Reserved
0x0
R
[6:4] CH3_GAIN_MD3
Receiver Mode 3 Channel 3 Gain
0x7
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH4_GAIN_MD3
Receiver Mode 3 Channel 4 Gain
0x7
R/W
0x04C
RX_EN_MODE_4
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD4
Receiver Mode 4 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD4
Receiver Mode 4 Channel 1 to Channel 2 Active
Splitter Enable
0x0
R/W
4
SPLT34_EN_MD4
Receiver Mode 4 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
3
CH1_EN_MD4
Receiver Mode 4 Channel 1 Enable
0x0
R/W
2
CH2_EN_MD4
Receiver Mode 4 Channel 2 Enable
0x0
R/W
1
CH3_EN_MD4
Receiver Mode 4 Channel 3 Enable
0x0
R/W
0
CH4_EN_MD4
Receiver Mode 4 Channel 4 Enable
0x1
R/W
0x04D
RX_GAIN12_MODE_4
7
RESERVED
Reserved
0x0
R
[6:4] CH1_GAIN_MD4
Receiver Mode 4 Channel 1 Gain
0x7
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH2_GAIN_MD4
Receiver Mode 4 Channel 2 Gain
0x7
R/W
0x04E
RX_GAIN34_MODE_4
7
RESERVED
Reserved
0x0
R
[6:4] CH3_GAIN_MD4
Receiver Mode 4 Channel 3 Gain
0x7
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH4_GAIN_MD4
Receiver Mode 4 Channel 4 Gain
0x7
R/W
0x04F
RX_EN_MODE_5
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD5
Receiver Mode 5 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD5
Receiver Mode 5 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
4
SPLT34_EN_MD5
Receiver Mode 5 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
3
CH1_EN_MD5
Receiver Mode 5 Channel 1 Enable
0x1
R/W
2
CH2_EN_MD5
Receiver Mode 5 Channel 2 Enable
0x1
R/W
1
CH3_EN_MD5
Receiver Mode 5 Channel 3 Enable
0x1
R/W
0
CH4_EN_MD5
Receiver Mode 5 Channel 4 Enable
0x1
R/W
0x050
RX_GAIN12_MODE_5
7
RESERVED
Reserved
0x0
R
[6:4] CH1_GAIN_MD5
Receiver Mode 5 Channel 1 Gain
0x7
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH2_GAIN_MD5
Receiver Mode 5 Channel 2 Gain
0x7
R/W
0x051
RX_GAIN34_MODE_5
7
RESERVED
Reserved
0x0
R
[6:4] CH3_GAIN_MD5
Receiver Mode 5 Channel 3 Gain
0x7
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH4_GAIN_MD5
Receiver Mode 5 Channel 4 Gain
0x7
R/W
0x052
RX_EN_MODE_6
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD6
Receiver Mode 6 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD6
Receiver Mode 6 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
4
SPLT34_EN_MD6
Receiver Mode 6 Channel 3 to Channel 4 Active
Splitter Enable
0x0
R/W
3
CH1_EN_MD6
Receiver Mode 6 Channel 1 Enable
0x1
R/W
2
CH2_EN_MD6
Receiver Mode 6 Channel 2 Enable
0x0
R/W
1
CH3_EN_MD6
Receiver Mode 6 Channel 3 Enable
0x0
R/W
0
CH4_EN_MD6
Receiver Mode 6 Channel 4 Enable
0x0
R/W
