background image
Data Sheet
ADAR2004
Rev. 0 | Page 31 of 37
Address Name
Bits Bit Name
Description
Reset Access
0x05B
RX_EN_MODE_9
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD9
Receiver Mode 9 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD9
Receiver Mode 9 Channel 1 to Channel 2 Active
Splitter Enable
0x0
R/W
4
SPLT34_EN_MD9
Receiver Mode 9 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
3
CH1_EN_MD9
Receiver Mode 9 Channel 1 Enable
0x0
R/W
2
CH2_EN_MD9
Receiver Mode 9 Channel 2 Enable
0x0
R/W
1
CH3_EN_MD9
Receiver Mode 9 Channel 3 Enable
0x0
R/W
0
CH4_EN_MD9
Receiver Mode 9 Channel 4 Enable
0x1
R/W
0x05C
RX_GAIN12_MODE_9
7
RESERVED
Reserved
0x0
R
[6:4] CH1_GAIN_MD9
Receiver Mode 9 Channel 1 Gain
0x4
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH2_GAIN_MD9
Receiver Mode 9 Channel 2 Gain
0x4
R/W
0x05D
RX_GAIN34_MODE_9
7
RESERVED
Reserved
0x0
R
[6:4] CH3_GAIN_MD9
Receiver Mode 9 Channel 3 Gain
0x4
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH4_GAIN_MD9
Receiver Mode 9 Channel 4 Gain
0x4
R/W
0x05E
RX_EN_MODE_10
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD10
Receiver Mode 10 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD10
Receiver Mode 10 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
4
SPLT34_EN_MD10
Receiver Mode 10 Channel 3 to Channel 4 Active
Splitter Enable
0x1
R/W
3
CH1_EN_MD10
Receiver Mode 10 Channel 1 Enable
0x1
R/W
2
CH2_EN_MD10
Receiver Mode 10 Channel 2 Enable
0x1
R/W
1
CH3_EN_MD10
Receiver Mode 10 Channel 3 Enable
0x1
R/W
0
CH4_EN_MD10
Receiver Mode 10 Channel 4 Enable
0x1
R/W
0x05F
RX_GAIN12_MODE_10
7
RESERVED
Reserved
0x0
R
[6:4] CH1_GAIN_MD10
Receiver Mode 10 Channel 1 Gain
0x4
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH2_GAIN_MD10
Receiver Mode 10 Channel 2 Gain
0x4
R/W
0x060
RX_GAIN34_MODE_10
7
RESERVED
Reserved
0x0
R
[6:4] CH3_GAIN_MD10
Receiver Mode 10 Channel 3 Gain
0x4
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH4_GAIN_MD10
Receiver Mode 10 Channel 4 Gain
0x4
R/W
0x061
RX_EN_MODE_11
7
RESERVED
Reserved
0x0
R
6
SPLT1_EN_MD11
Receiver Mode 11 Active Splitter 1 Enable
0x1
R/W
5
SPLT12_EN_MD11
Receiver Mode 11 Channel 1 to Channel 2 Active
Splitter Enable
0x1
R/W
4
SPLT34_EN_MD11
Receiver Mode 11 Channel 3 to Channel 4 Active
Splitter Enable
0x0
R/W
3
CH1_EN_MD11
Receiver Mode 11 Channel 1 Enable
0x1
R/W
2
CH2_EN_MD11
Receiver Mode 11 Channel 2 Enable
0x0
R/W
1
CH3_EN_MD11
Receiver Mode 11 Channel 3 Enable
0x0
R/W
0
CH4_EN_MD11
Receiver Mode 11 Channel 4 Enable
0x0
R/W
0x062
RX_GAIN12_MODE_11
7
RESERVED
Reserved
0x0
R
[6:4] CH1_GAIN_MD11
Receiver Mode 11 Channel 1 Gain
0x0
R/W
3
RESERVED
Reserved
0x0
R
[2:0] CH2_GAIN_MD11
Receiver Mode 11 Channel 2 Gain
0x0
R/W
