www.dfi.com
MECHANICAL DRAWING
BLOCK DIAGRAM
HSIO P14-16
PCIE_LANE [4:7]
Channel A
HSIO P13
Intel
I226
MDI
PCIE x1
NBASET0
HSIO P17
Intel
I226
PCIe x1
MDI
NBASET1
PCIE x4
HSIO P10-11
HSIO P22-25
PCIE_LANE [0:1]
2* PCIE x1
x8 DMI 4.0
PCIe Gen3
PCIe Gen3
PCIE_LANE [12:15]
PCIE x4
PCIe Gen4
PCIe Gen4
PCIe Gen5
HSIO P30-33
PCIE_LANE [8:11]
PCIE x4
eDP Port
DDI_A
DDI Port 1
DDI_C
DDI Port 0
DDI_B
HSIO P26-27
SATA 0/1
SATA 3.0 x2
HDA SNDW
HDA SNDW0/1
HDA
ESPI
ESPI
eSPI
GSPI
SMBUS_RESUME
I2C0
GSPI 0/1
GSPI
SPI BUS
SPI
SPI
TPM 2.0
(Option)
SPI Flash BIOS
(256M bit)
USB 3.2 Gen2 x2
USB 2.0 x1
USB1_SS P0-P1
HSIO P6-7
USB 3.2 Gen2 x2
USB 2.0 x1
2 Ports USB 3.2 Gen2 x1
USB 2.0 x2
USB0_SS P0-P1
USB 2.0 x2
USB6/USB7
HSIO P0-1
Embedded
Controller
IT8528VG-I
I2C1 1.8V
I2C4
Serial Port 1,2
12bits DIO
I2C BUS
SLP/LID
I2C_SMB
SMBUS (OPTION)
(OPTION)
SMBUS
WDT
Fan PWM/TACH_IN
DDR5 3600 MHz
DDR5 3600 MHz
Channel B
DDI Port 2
DDI_D
PCIE_LANE [16:31]
PCIe x16
PCIe Gen4
PCIE_LANE [32:35]
PCIe x4
HSIO P18-21
PCIe Gen3
PCIE_LANE [36:39]
PCIe x4
HSIO P34-37
PCIe Gen4
PCIE_LANE [40:43]
PCIe x4
HSIO P2-3
USB2_SS P0-P1
2 Ports USB 3.2 Gen2 x1
USB 2.0 x2
HSIO P4-5
USB3_SS P0-P1
Intel Raptor-Lake
CPU
Intel ADL-S
PCH
Q670E
LGA 1700
65W
SO-DIMM 2DPC
CMOS Backup
EEPROM
I2C0
USB_PD_I2C
SMBUS
GPIO [0:11]
UART0/1
120.00
0.00
6.00
114.00
116.00
106.00
101.13
77.13
33.19
98.15
54.85
55.30
0.00
110.00
10.00
120.00
