SPECIFICATION

SYSTEM

Processor

14th Gen Intel® Core™ Processors, LGA 1700 Socket Processors, TDP support up to 65W

Intel® Core™ I9-14900 (24 Cores, 36M Cache, up to 5.8 GHz); 65W

Intel® Core™ I9-14900T (24 Cores, 36M Cache, up to 5.5 GHz); 35W

Intel® Core™ I7-14700 (20 Cores, 33M Cache, up to 5.4 GHz); 65W

Intel® Core™ I7-14700T (20 Cores, 33M Cache, up to 5.2 GHz); 35W

Intel® Core™ I5-14500 (14 Cores, 24M Cache, up to 5.0 GHz); 65W

Intel® Core™ I5-14500T (14 Cores, 24M Cache, up to 4.8 GHz); 35W

Intel® Core™ I5-14400 (10 Cores, 20M Cache, up to 4.7 GHz); 65W

Intel® Core™ I5-14400T (10 Cores, 20M Cache, up to 4.5 GHz); 35W

Intel® Core™ I3-14100 (4 Cores, 12M Cache, up to 4.7 GHz); 60W

Intel® Core™ I3-14100T (4 Cores, 12M Cache, up to 4.4 GHz); 35W

13th Gen Intel® Core™ Processors, LGA 1700 Socket Processors, TDP support up to 65W

Intel® Core™ I9-13900E (24 Cores, 36M Cache, up to 5.2 GHz); 65W

Intel® Core™ I9-13900TE (24 Cores, 36M Cache, up to 5.0 GHz); 35W

Intel® Core™ I7-13700E (16 Cores, 30M Cache, up to 5.1 GHz); 65W

Intel® Core™ I7-13700TE (16 Cores, 30M Cache, up to 4.8 GHz); 35W

Intel® Core™ I7-13700T (16 Cores, 30M Cache, up to 4.9 GHz); 35W

Intel® Core™ I5-13500E (14 Cores, 24M Cache, up to 4.6 GHz); 65W

Intel® Core™ I5-13500TE (14 Cores, 24M Cache, up to 4.5 GHz); 35W

Intel® Core™ I5-13500T (14 Cores, 24M Cache, up to 4.6 GHz); 35W

Intel® Core™ I5-13400E (10 Cores, 20M Cache, up to 4.6 GHz); 65W

Intel® Core™ I3-13100E (4 Cores, 12M Cache, up to 3.3 GHz); 60W

Intel® Core™ I3-13100TE (4 Cores, 12M Cache, up to 4.1 GHz); 35W

Intel® Core™ I3-13100T (4 Cores, 12M Cache, up to 4.2 GHz); 35W

Chipset

Intel® R680E/Q670E/H610E Chipset

Memory

4pcs DDR5 SO-DIMM up to 192GB

Dual Channel DDR5

ECC support by R680 with i7 and i5

BIOS

AMI SPI 256Mbit

GRAPHICS

Controller

Intel® HD Gen 9 Graphics

Feature

OpenGL 4.5, DirectX 12, OpenCL 2.1

HW Decode: AVC/H.264, MPEG2, VC1/WMV9, JPEG/MJPEG, HEVC/H265, VP8, VP9

HW Encode: MPEG2, AVC/H264, JPEG, HEVC/H265, VP8, VP9

Display

3 x DDI (HDMI/DP++) support to 8K

1 x eDP support to 5K

Multiple Displays

eDP + 3 DDI

EXPANSION

Interface

1 x PCIe x16 (Gen5)

4 x PCIe x4 (Gen4)

2 x PCIe x4 (Gen3)

2 x PCIe x1 (Gen3)

1 x eSPI

1 x I2C

1 x SMBus

2 x UART (TX/RX/RTS/CTS)

AUDIO

Audio Codec

HD Audio

ETHERNET

Phy

2 x Intel® I226 series (10/100/1000Mbps/2.5G)

I/O

USB

4 x USB 3.2 Gen2

8 x USB 2.0

SATA

2 x SATA 3.0 (up to 6Gb/s)

GPIO

12 bit in/out

WATCHDOG TIMER

Output & Interval

System Reset, Programmable via Software from 1 to 255 Seconds

SECURITY

TPM

TPM2.0 (Available Upon Request)

POWER

Type

12V, 5VSB, VCC_RTC (ATX mode)

12V, VCC_RTC (AT mode)

Consumption

TBD

OS SUPPORT

Microsoft

Windows 10 IoT Enterprise 64-bit

Windows 11

Linux

Ubuntu 20.04

ENVIRONMENT

Temperature

Operating: 0 to 60°C

Storage: -40 to 85°C

Humidity

Operating: 5 to 90% RH

Storage: 5 to 90% RH

MTBF

TBD

MECHANICAL

Dimensions

COM HPC® Client Size C

6.30" x 4.72" (160mm x 120mm)

Compliance

PICMG COM HPC® R1.15, Client Size C

STANDARDS AND

CERTIFICATIONS

Certification

CE, FCC, RoHS
