RPS9HC-R680E-BS datasheet(1/4 Pages) DFI

Part #	RPS9HC-R680E-BS

Description	14th/13th Gen Intel® Core™ COM HPC® Client Size C

PDF	4 Pages

Scroll/Zoom	100%

Manufacturer	DFI [DFI Inc]

Direct Link	https://www.dfi.com/

Logo

1 / 4 page

KEY FEATURES

DDR5

8K High

Resolution

Quad

Displays

Multiple

Expansion

RICH I/O

4 DDR5 SODIMM up to

192GB

DDI supports up to 8K

4 Display ports:

eDP + 3DDI

1 PCIe x16 (Gen5),

4 PCIe x4 (Gen4),

2 PCIe x4 (Gen3),

2 PCIe x1 (Gen3)

2 Intel 2.5GbE,

6 USB 3.2 Gen2,

8 USB 2.0

14th/13th Gen Intel® Core™

COM HPC® Client Size C

RPS9HC-

R680E/Q670E/H610E

Bottom View

Front View

DDR5 SO-DIMM3

DDR5 SO-DIMM4

DDR5 SO-DIMM1

DDR5 SO-DIMM2

CPU Fan

FCLGA1700

Intel® PCH

R680E/Q670E/H610E

8K
