E3X-NH

E3X-NH

3

Indicates models that allow free cutting. Models without this mark do not allow free cutting.

: E3X-NH

j

: E3X-NHB

j

Applicatio

n

Features

Appearance

Sensing distance (mm) *1

(Values in parentheses: when

using the E39-F1 Lens Unit)

Standard

object

(min. sensing

object:

opaque)

Model

Permis-

sible

bending

radius

Chemical-

resistant

PTFE-covered*4; withstands

chemicals and harsh

environments

(operating ambient temperature:

–30

_C to 70_C)

5-mm dia.

1,600

220

4.0-mm dia.

(0.12-mm dia.)

E32-T12F

40 mm

PTFE covered*4 ; side-view;

withstands chemicals and harsh

environments (operating ambient

temperature: –30

_C to 70_C)

5-mm dia.

200

3.0-mm dia.

(0.12-mm dia.)

E32-T14F

Heat-resis

tant

Resists 150

°C*3; fiber sheath

material: fluororesin (operating

ambient temperature: –40

_C to

150

_C)

M4 screw

400

35

1.5-mm dia.

(0.4-mm dia.)

E32-T51

35 mm

Side-view; resists 150

°C*3 ;

suitable for detecting minute

sensing objects; fiber sheath

material: fluororesin (operating

ambient temperature: –40

_C to

150

_C)

2-mm dia.

130

1.0-mm dia.

(0.16-mm dia.)

E32-T54

Resists 300

°C*5, with spiral tube;

high mechanical strength; fiber

sheath material: stainless steel

(operating ambient temperature:

–40

_C to 300_C)

M4 screw

300

(3,000)

1.0-mm dia.

(0.12-mm dia.)

E32-T61

25 mm

Resists 200

°C*5; L-shaped; fiber

sheath material: stainless steel

700

1.7-mm dia.

(0.12-mm dia.)

E32-T84S

Slot

Suitable for film sheet detection;

no optical axis adjustment

required; easy to mount

10

4.0-mm dia.

(0.16-mm dia.)

E32-G14

25 mm

Narrow

vision

field

Suitable for detecting wafers;

3-mm dia.

1,000

1.7-mm dia.

(0.08-mm dia.)

E32-T22S

10 mm

Side-view; suitable for detecting

wafers;

3.5 x 3 mm dia.

700

2-mm dia.

(0.04-mm dia.)

E32-T24S

Area

sensing

through-b

eam

Multi-point

sensing (4-head)

M3 screw

300

2.0-mm dia.

(0.04-mm dia.)

E32-M21

25 mm

Stable for detecting minute

sensing objects in a wide area;

degree of protection: IEC60529

IP50

600

(0.4-mm

dia.)*6

E32-T16P

10 mm

Suitable for detecting over a

10-mm area; long distance

10 mm

1,500

700

(2.0-mm

dia.)*6

E32-T16

25 mm

Note:

1. For common specifications of the Fiber Unit, refer to page 6.

2. The size of standard sensing object is the same as the fiber core diameter (lens diameter for models with lens).

3. The sensing distance of the minimum sensing object indicates the rated sensing distance unless otherwise specified.

*1 Sensing distance indicates values for white paper.

*2 For continuous operation, use the products within the temperature ranging from –40

_C to 130_C.

*3 PTFE is a registered trademark of the Dupont Company and the Mitsui Dupont Chemical Company for their fluoride resin.

*4 Indicates the heat-resistant temperature at the fiber tip. For further details, refer to page 26.

*5 Indicates values for the sensing distance of 100 mm.
