E5EC-T/E5AC-T

Specifications

Ratings

Power supply voltage

A in model number: 100 to 240 VAC, 50/60 Hz

D in model number: 24 VAC, 50/60 Hz; 24 VDC

Operating voltage range

85 to 110% of rated supply voltage

Power consumption

E5EC-T 8.7 VA max. at 100 to 240 VAC, and 5.5 VA max. at 24 VAC or 3.2 W max. at 24 VDC

E5AC-T 9.0 VA max. at 100 to 240 VAC, and 5.6 VA max. at 24 VAC or 3.4 W max. at 24 VDC

Sensor input

Temperature input

Thermocouple: K, J, T, E, L, U, N, R, S, B, C/W, or PL II

Platinum resistance thermometer: Pt100 or JPt100

Infrared temperature sensor (ES1B): 10 to 70°C, 60 to 120°C, 115 to 165°C, or 140 to 260°C

Analog input

Current input: 4 to 20 mA or 0 to 20 mA

Voltage input: 1 to 5 V, 0 to 5 V, or 0 to 10 V

Input impedance

Current input: 150

Ω max., Voltage input: 1 MΩ min.

(Use a 1:1 connection when connecting the ES2-HB-N/THB-N.)

Control method

2-PID control (with auto-tuning) or ON/OFF control

Control

output

Relay output

SPST-NO, 250 VAC, 5 A (resistive load), electrical life: 100,000 operations,

minimum applicable load: 5 V, 10 mA (reference value)

Voltage output

(for driving SSR)

Output voltage: 12 VDC

±20% (PNP), max. load current: 40 mA, with short-circuit protection circuit

(The maximum load current is 21 mA for models with two control outputs.)

Linear current output

4 to 20 mA DC/0 to 20 mA DC, load: 500

Ω max., resolution: approx. 10,000

Auxiliary

output

Number of outputs

Output specifications

SPST-NO. relay outputs, 250 VAC, Models with 4 outputs: 2 A (resistive load),

Electrical life: 100,000 operations, Minimum applicable load: 10 mA at 5 V (reference value)

Event input

Number of inputs

2, 4 or 6 (depends on model)

External contact input

specifications

Contact input: ON: 1 k

Ω max., OFF: 100 kΩ min.

Non-contact input: ON: Residual voltage: 1.5 V max., OFF: Leakage current: 0.1 mA max.

Current flow: Approx. 7 mA per contact

Transfer

output

Number of outputs

1 (only on models with a transfer output)

Output specifications

Current output: 4 to 20 mA DC, Load: 500

Ω max., Resolution: Approx. 10,000

Linear voltage output: 1 to 5 VDC, load: 1 k

Ω min., Resolution: Approx. 10,000

Potentiometer input

100

Ω to 10 kΩ

Setting method

Digital setting using front panel keys

Indication method

11-segment digital display and individual indicators

Character height:

E5EC-T: PV: 18.0 mm, SV: 11.0 mm, MV: 7.8 mm

E5AC-T: PV: 25.0 mm, SV: 15.0 mm, MV: 9.5 mm

Three displays. Contents: PV, SP, program No. and segment No., remaining segment time, or MV

(valve opening)

Numbers of digits: 4 digits

Bank switching

None

Other functions

Manual output, heating/cooling control, loop burnout alarm, other alarm functions, heater burnout (HB)

alarm (including SSR failure (HS) alarm), 40% AT, 100% AT, MV limiter, input digital filter, robust

tuning, PV input shift, protection functions, extraction of square root, MV change rate limit, logic

operations, temperature status display, moving average of input value, and display brightness setting

Ambient operating temperature

−10 to 55°C (with no condensation or icing), For 3-year warranty: −10 to 50°C with standard mounting

(with no condensation or icing)

Ambient operating humidity

25 to 85%

Storage temperature

−25 to 65°C (with no condensation or icing)

Altitude

2,000 m max.

Recommended fuse

T2A, 250 VAC, time-lag, low-breaking capacity

Installation environment

Overvoltage category II, Pollution Degree 2 (EN/IEC/UL 61010-1)
