Section 17 I

2C Bus Interface 2 (IIC2)

Rev.1.00 Jun. 07, 2006 Page 827 of 1102

REJ09B0294-0100

Bit

Bit Name

Initial

Value

R/W

Description

STIE

R/W

Stop Condition Detection Interrupt Enable

0: Stop condition detection interrupt (STPI) request is

disabled

1: Stop condition detection interrupt (STPI) request is

enabled

ACKE

R/W

Acknowledge Bit Decision Select

0: The value of the acknowledge bit is ignored and

continuous transfer is performed

1: If the acknowledge bit is 1, continuous transfer is

suspended

ACKBR

Receive Acknowledge

In transmit mode, this bit stores the acknowledge data

that are returned by the receive device. This bit cannot

be modified.

0: Receive acknowledge = 0

1: Receive acknowledge = 1

ACKBT

R/W

Transmit Acknowledge

In receive mode, this bit specifies the bit to be sent at

the acknowledge timing.

0: 0 is sent at the acknowledge timing

1: 1 is sent at the acknowledge timing
