H8SX/1663 Datasheet(PDF) 1058 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1058 Page - Renesas Technology Corp |
|
|
1058 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1006 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Timer counter_0 TCNT_0 8 H'FFFB8 TMR_0 16 2P φ/2Pφ Timer counter_1 TCNT_1 8 H'FFFB9 TMR_1 16 2P φ/2Pφ Timer counter control register_0 TCCR_0 8 H'FFFBA TMR_0 16 2P φ/2Pφ Timer counter control register_1 TCCR_1 8 H'FFFBB TMR_1 16 2P φ/2Pφ Timer start register TSTR 8 H'FFFBC TPU 16 2P φ/2Pφ Timer synchronous register TSYR 8 H'FFFBD TPU 16 2P φ/2Pφ Timer control register_0 TCR_0 8 H'FFFC0 TPU_0 16 2P φ/2Pφ Timer mode register_0 TMDR_0 8 H'FFFC1 TPU_0 16 2P φ/2Pφ Timer I/O control register H_0 TIORH_0 8 H'FFFC2 TPU_0 16 2P φ/2Pφ Timer I/O control register L_0 TIORL_0 8 H'FFFC3 TPU_0 16 2P φ/2Pφ Timer interrupt enable register_0 TIER_0 8 H'FFFC4 TPU_0 16 2P φ/2Pφ Timer status register_0 TSR_0 8 H'FFFC5 TPU_0 16 2P φ/2Pφ Timer counter_0 TCNT_0 16 H'FFFC6 TPU_0 16 2P φ/2Pφ Timer general register A_0 TGRA_0 16 H'FFFC8 TPU_0 16 2P φ/2Pφ Timer general register B_0 TGRB_0 16 H'FFFCA TPU_0 16 2P φ/2Pφ Timer general register C_0 TGRC_0 16 H'FFFCC TPU_0 16 2P φ/2Pφ Timer general register D_0 TGRD_0 16 H'FFFCE TPU_0 16 2P φ/2Pφ Timer control register_1 TCR_1 8 H'FFFD0 TPU_1 16 2P φ/2Pφ Timer mode register_1 TMDR_1 8 H'FFFD1 TPU_1 16 2P φ/2Pφ Timer I/O control register_1 TIOR_1 8 H'FFFD2 TPU_1 16 2P φ/2Pφ Timer interrupt enable register_1 TIER_1 8 H'FFFD4 TPU_1 16 2P φ/2Pφ Timer status register_1 TSR_1 8 H'FFFD5 TPU_1 16 2P φ/2Pφ Timer counter_1 TCNT_1 16 H'FFFD6 TPU_1 16 2P φ/2Pφ Timer general register A_1 TGRA_1 16 H'FFFD8 TPU_1 16 2P φ/2Pφ Timer general register B_1 TGRB_1 16 H'FFFDA TPU_1 16 2P φ/2Pφ Timer control register_2 TCR_2 8 H'FFFE0 TPU_2 16 2P φ/2Pφ Timer mode register_2 TMDR_2 8 H'FFFE1 TPU_2 16 2P φ/2Pφ Timer I/O control register_2 TIOR_2 8 H'FFFE2 TPU_2 16 2P φ/2Pφ Timer interrupt enable register_2 TIER_2 8 H'FFFE4 TPU_2 16 2P φ/2Pφ Timer status register_2 TSR_2 8 H'FFFE5 TPU_2 16 2P φ/2Pφ Timer counter_2 TCNT_2 16 H'FFFE6 TPU_2 16 2P φ/2Pφ Timer general register A_2 TGRA_2 16 H'FFFE8 TPU_2 16 2P φ/2Pφ Timer general register B_2 TGRB_2 16 H'FFFEA TPU_2 16 2P φ/2Pφ Timer control register_3 TCR_3 8 H'FFFF0 TPU_3 16 2P φ/2Pφ Timer mode register_3 TMDR_3 8 H'FFFF1 TPU_3 16 2P φ/2Pφ |
|
