H8SX/1663 Datasheet(PDF) 1055 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1055 Page - Renesas Technology Corp |
|
|
1055 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1003 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Timer control register_4 TCR_4 8 H'FFEE0 TPU_4 16 2P φ/2Pφ Timer mode register_4 TMDR_4 8 H'FFEE1 TPU_4 16 2P φ/2Pφ Timer I/O control register_4 TIOR_4 8 H'FFEE2 TPU_4 16 2P φ/2Pφ Timer interrupt enable register_4 TIER_4 8 H'FFEE4 TPU_4 16 2P φ/2Pφ Timer status register_4 TSR_4 8 H'FFEE5 TPU_4 16 2P φ/2Pφ Timer counter_4 TCNT_4 16 H'FFEE6 TPU_4 16 2P φ/2Pφ Timer general register A_4 TGRA_4 16 H'FFEE8 TPU_4 16 2P φ/2Pφ Timer general register B_4 TGRB_4 16 H'FFEEA TPU_4 16 2P φ/2Pφ Timer control register_5 TCR_5 8 H'FFEF0 TPU_5 16 2P φ/2Pφ Timer mode register_5 TMDR_5 8 H'FFEF1 TPU_5 16 2P φ/2Pφ Timer I/O control register_5 TIOR_5 8 H'FFEF2 TPU_5 16 2P φ/2Pφ Timer interrupt enable register_5 TIER_5 8 H'FFEF4 TPU_5 16 2P φ/2Pφ Timer status register_5 TSR_5 8 H'FFEF5 TPU_5 16 2P φ/2Pφ Timer counter_5 TCNT_5 16 H'FFEF6 TPU_5 16 2P φ/2Pφ Timer general register A_5 TGRA_5 16 H'FFEF8 TPU_5 16 2P φ/2Pφ Timer general register B_5 TGRB_5 16 H'FFEFA TPU_5 16 2P φ/2Pφ DTC enable register A DTCERA 16 H'FFF20 INTC 16 2I φ/3Iφ DTC enable register B DTCERB 16 H'FFF22 INTC 16 2I φ/3Iφ DTC enable register C DTCERC 16 H'FFF24 INTC 16 2I φ/3Iφ DTC enable register D DTCERD 16 H'FFF26 INTC 16 2I φ/3Iφ DTC enable register E DTCERE 16 H'FFF28 INTC 16 2I φ/3Iφ DTC enable register G DTCERG 16 H'FFF2C INTC 16 2I φ/3Iφ DTC enable register H DTCERH 16 H'FFF2E INTC 16 2I φ/3Iφ DTC control register DTCCR 8 H'FFF30 INTC 16 2I φ/3Iφ Interrupt control register INTCR 8 H'FFF32 INTC 16 2I φ/3Iφ CPU priority control register CPUPCR 8 H'FFF33 INTC 16 2I φ/3Iφ IRQ enable register IER 16 H'FFF34 INTC 16 2I φ/3Iφ IRQ status register ISR 16 H'FFF36 INTC 16 2I φ/3Iφ Port 1 register PORT1 8 H'FFF40 I/O port 8 2P φ/— Port 2 register PORT2 8 H'FFF41 I/O port 8 2P φ/— Port 3 register PORT3 8 H'FFF42 I/O port 8 2P φ/— Port 5 register PORT5 8 H'FFF44 I/O port 8 2P φ/— Port 6 register PORT6 8 H'FFF45 I/O port 8 2P φ/— Port A register PORTA 8 H'FFF49 I/O port 8 2P φ/— Port B register PORTB 8 H'FFF4A I/O port 8 2P φ/— |
|
