H8SX/1663 Datasheet(PDF) 1052 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1052 Page - Renesas Technology Corp |
|
|
1052 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1000 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) DMA offset register_2 DOFR_2 32 H'FFC48 DMAC_2 16 2I φ/2Iφ DMA transfer count register_2 DTCR_2 32 H'FFC4C DMAC_2 16 2I φ/2Iφ DMA block size register_2 DBSR_2 32 H'FFC50 DMAC_2 16 2I φ/2Iφ DMA mode control register_2 DMDR_2 32 H'FFC54 DMAC_2 16 2I φ/2Iφ DMA address control register_2 DACR_2 32 H'FFC58 DMAC_2 16 2I φ/2Iφ DMA source address register_3 DSAR_3 32 H'FFC60 DMAC_3 16 2I φ/2Iφ DMA destination address register_3 DDAR_3 32 H'FFC64 DMAC_3 16 2I φ/2Iφ DMA offset register_3 DOFR_3 32 H'FFC68 DMAC_3 16 2I φ/2Iφ DMA transfer count register_3 DTCR_3 32 H'FFC6C DMAC_3 16 2I φ/2Iφ DMA block size register_3 DBSR_3 32 H'FFC70 DMAC_3 16 2I φ/2Iφ DMA mode control register_3 DMDR_3 32 H'FFC74 DMAC_3 16 2I φ/2Iφ DMA address control register_3 DACR_3 32 H'FFC78 DMAC_3 16 2I φ/2Iφ DMA module request select register_0 DMRSR_0 8 H'FFD20 DMAC_0 16 2I φ/2Iφ DMA module request select register_1 DMRSR_1 8 H'FFD21 DMAC_1 16 2I φ/2Iφ DMA module request select register_2 DMRSR_2 8 H'FFD22 DMAC_2 16 2I φ/2Iφ DMA module request select register_3 DMRSR_3 8 H'FFD23 DMAC_3 16 2I φ/2Iφ Interrupt priority register A IPRA 16 H'FFD40 INTC 16 2I φ/3Iφ Interrupt priority register B IPRB 16 H'FFD42 INTC 16 2I φ/3Iφ Interrupt priority register C IPRC 16 H'FFD44 INTC 16 2I φ/3Iφ Interrupt priority register D IPRD 16 H'FFD46 INTC 16 2I φ/3Iφ Interrupt priority register E IPRE 16 H'FFD48 INTC 16 2I φ/3Iφ Interrupt priority register F IPRF 16 H'FFD4A INTC 16 2I φ/3Iφ Interrupt priority register G IPRG 16 H'FFD4C INTC 16 2I φ/3Iφ Interrupt priority register H IPRH 16 H'FFD4E INTC 16 2I φ/3Iφ Interrupt priority register I IPRI 16 H'FFD50 INTC 16 2I φ/3Iφ Interrupt priority register K IPRK 16 H'FFD54 INTC 16 2I φ/3Iφ Interrupt priority register L IPRL 16 H'FFD56 INTC 16 2I φ/3Iφ Interrupt priority register Q IPRQ 16 H'FFD60 INTC 16 2I φ/3Iφ Interrupt priority register R IPRR 16 H'FFD62 INTC 16 2I φ/3Iφ IRQ sense control register H ISCRH 16 H'FFD68 INTC 16 2I φ/3Iφ IRQ sense control register L ISCRL 16 H'FFD6A INTC 16 2I φ/3Iφ DTC vector base register DTCVBR 32 H'FFD80 BSC 16 2I φ/3Iφ Bus width control register ABWCR 16 H'FFD84 BSC 16 2I φ/3Iφ Access state control register ASTCR 16 H'FFD86 BSC 16 2I φ/3Iφ Wait control register A WTCRA 16 H'FFD88 BSC 16 2I φ/3Iφ Wait control register B WTCRB 16 H'FFD8A BSC 16 2I φ/3Iφ |
|
