H8SX/1663 Datasheet(PDF) 1053 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1053 Page - Renesas Technology Corp |
|
|
1053 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1001 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Read strobe timing control register RDNCR 16 H'FFD8C BSC 16 2I φ/3Iφ CS assertion period control register CSACR 16 H'FFD8E BSC 16 2I φ/3Iφ Idle control register IDLCR 16 H'FFD90 BSC 16 2I φ/3Iφ Bus control register1 BCR1 16 H'FFD92 BSC 16 2I φ/3Iφ Bus control register2 BCR2 8 H'FFD94 BSC 16 2I φ/3Iφ Endian control register ENDIANCR 8 H'FFD95 BSC 16 2I φ/3Iφ SRAM mode control register SRAMCR 16 H'FFD98 BSC 16 2I φ/3Iφ Burst ROM interface control register BROMCR 16 H'FFD9A BSC 16 2I φ/3Iφ Address/data multiplexed I/O control register MPXCR 16 H'FFD9C BSC 16 2I φ/3Iφ DRAM control register DRAMCR 16 H'FFDA0 BSC 16 2I φ/3Iφ DRAM access control register DRACCR 16 H'FFDA2 BSC 16 2I φ/3Iφ Synchronous DRAM control register SDCR 16 H'FFDA4 BSC 16 2I φ/3Iφ Refresh control register REFCR 16 H'FFDA6 BSC 16 2I φ/3Iφ Refresh timer counter RTCNT 8 H'FFDA8 BSC 16 2I φ/3Iφ Refresh time constant register RTCOR 8 H'FFDA9 BSC 16 2I φ/3Iφ RAM emulation register RAMER 8 H'FFD9E BSC 16 2I φ/3Iφ Mode control register MDCR 16 H'FFDC0 SYSTEM 16 2I φ/3Iφ System control register SYSCR 16 H'FFDC2 SYSTEM 16 2I φ/3Iφ System clock control register SCKCR 16 H'FFDC4 SYSTEM 16 2I φ/3Iφ Standby control register SBYCR 16 H'FFDC6 SYSTEM 16 2I φ/3Iφ Module stop control register A MSTPCRA 16 H'FFDC8 SYSTEM 16 2I φ/3Iφ Module stop control register B MSTPCRB 16 H'FFDCA SYSTEM 16 2I φ/3Iφ Module stop control register C MSTPCRC 16 H'FFDCC SYSTEM 16 2I φ/3Iφ Subclock control register SUBCKCR 8 H'FFDCF SYSTEM 8 2I φ/2Iφ Serial extended mode register_2 SEMR_2 8 H'FFE84 SCI_2 8 2P φ/2Pφ Serial mode register_4 SMR_4 8 H'FFE90 SCI_4 8 2P φ/2Pφ Bit rate register_4 BRR_4 8 H'FFE91 SCI_4 8 2P φ/2Pφ Serial control register_4 SCR_4 8 H'FFE92 SCI_4 8 2P φ/2Pφ Transmit data register_4 TDR_4 8 H'FFE93 SCI_4 8 2P φ/2Pφ Serial status register_4 SSR_4 8 H'FFE94 SCI_4 8 2P φ/2Pφ Receive data register_4 RDR_4 8 H'FFE95 SCI_4 8 2P φ/2Pφ Smart card mode register_4 SCMR_4 8 H'FFE96 SCI_4 8 2P φ/2Pφ |
|
