H8SX/1663 Datasheet(PDF) 1049 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1049 Page - Renesas Technology Corp |
|
|
1049 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 997 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Interrupt select register 0 ISR0 8 H'FEE08 USB 8 3P φ/3Pφ Interrupt select register 1 ISR1 8 H'FEE09 USB 8 3P φ/3Pφ Interrupt select register 2 ISR2 8 H'FEE0A USB 8 3P φ/3Pφ EP0i data register EPDR0i 8 H'FEE0C USB 8 3P φ/3Pφ EP0o data register EPDR0o 8 H'FEE0D USB 8 3P φ/3Pφ EP0s data register EPDR0s 8 H'FEE0E USB 8 3P φ/3Pφ EP1 data register EPDR1 8 H'FEE10 USB 8 3P φ/3Pφ EP2 data register EPDR2 8 H'FEE14 USB 8 3P φ/3Pφ EP3 data register EPDR3 8 H'FEE18 USB 8 3P φ/3Pφ EP0o receive data size register EPSZ0o 8 H'FEE24 USB 8 3P φ/3Pφ EP1 receive data size register EPSZ1 8 H'FEE25 USB 8 3P φ/3Pφ Data status register DASTS 8 H'FEE27 USB 8 3P φ/3Pφ FIFO clear register FCLR 8 H'FEE28 USB 8 3P φ/3Pφ Endpoint stall register EPSTL 8 H'FEE2A USB 8 3P φ/3Pφ Trigger register TRG 8 H'FEE2C USB 8 3P φ/3Pφ DMA transfer setting register DMA 8 H'FEE2D USB 8 3P φ/3Pφ Configuration value register CVR 8 H'FEE2E USB 8 3P φ/3Pφ Control register CTLR 8 H'FEE2F USB 8 3P φ/3Pφ Endpoint information register EPIR 8 H'FEE32 USB 8 3P φ/3Pφ Transceiver testregister0 TRNTREG00 8 H'FEE44 USB 8 3P φ/3Pφ Transceiver testregister1 TRNTREG1 8 H'FEE45 USB 8 3P φ/3Pφ Port M data direction register PMDDR 8 H'FEE50 I/O port 8 3P φ/3Pφ Port M data register PMDR 8 H'FEE51 I/O port 8 3P φ/3Pφ Port M register PORTM 8 H'FEE52 I/O port 8 3P φ/— Port M input buffer control register PMICR 8 H'FEE53 I/O port 8 3P φ/3Pφ Serial mode register_5 SMR_5 8 H'FF600 SCI_5 8 3P φ/3Pφ Bit rate register_5 BRR_5 8 H'FF601 SCI_5 8 3P φ/3Pφ Serial control register_5 SCR_5 8 H'FF602 SCI_5 8 3P φ/3Pφ Transmit data register_5 TDR_5 8 H'FF603 SCI_5 8 3P φ/3Pφ Serial status register_5 SSR_5 8 H'FF604 SCI_5 8 3P φ/3Pφ Receive data register_5 RDR_5 8 H'FF605 SCI_5 8 3P φ/3Pφ Smart card mode register_5 SCMR_5 8 H'FF606 SCI_5 8 3P φ/3Pφ Serial extended mode register_5 SEMR_5 8 H'FF608 SCI_5 8 3P φ/3Pφ IrDA control register IrCR 8 H'FF60C SCI_5 8 3P φ/3Pφ Serial mode register_6 SMR_6 8 H'FF610 SCI_6 8 3P φ/3Pφ |
|
