H8SX/1663 Datasheet(PDF) 1054 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663 Datasheet(HTML) 1054 Page - Renesas Technology Corp |
|
|
1054 / 1158 page  Section 24 List of Registers Rev.1.00 Jun. 07, 2006 Page 1002 of 1102 REJ09B0294-0100 Register Name Abbreviation Number of Bits Address Module Data Width Access Cycles (Read/Write) Flash code control/status register FCCS 8 H'FFDE8 FLASH 16 2I φ/2Iφ Flash program code select register FPCS 8 H'FFDE9 FLASH 16 2I φ/2Iφ Flash erase code select register FECS 8 H'FFDEA FLASH 16 2I φ/2Iφ Flash key code register FKEY 8 H'FFDEC FLASH 16 2I φ/2Iφ Flash transfer destination address register FTDAR 8 H'FFDEE FLASH 16 2I φ/2Iφ I 2C bus control register A_0 ICCRA_0 8 H'FFEB0 IIC2_0 8 2P φ/2Pφ I 2C bus control register B_0 ICCRB_0 8 H'FFEB1 IIC2_0 8 2P φ/2Pφ I 2C bus mode register_0 ICMR_0 8 H'FFEB2 IIC2_0 8 2P φ/2Pφ I 2C bus interrupt enable register_0 ICIER_0 8 H'FFEB3 IIC2_0 8 2P φ/2Pφ I 2C bus status register_0 ICSR_0 8 H'FFEB4 IIC2_0 8 2P φ/2Pφ Slave address register_0 SAR_0 8 H'FFEB5 IIC2_0 8 2P φ/2Pφ I 2C bus transmit data register_0 ICDRT_0 8 H'FFEB6 IIC2_0 8 2P φ/2Pφ I 2C bus receive data register_0 ICDRR_0 8 H'FFEB7 IIC2_0 8 2P φ/2Pφ I 2C bus control register A_1 ICCRA_1 8 H'FFEB8 IIC2_1 8 2P φ/2Pφ I 2C bus control register B_1 ICCRB_1 8 H'FFEB9 IIC2_1 8 2P φ/2Pφ I 2C bus mode register_1 ICMR_1 8 H'FFEBA IIC2_1 8 2P φ/2Pφ I 2C bus interrupt enable register_1 ICIER_1 8 H'FFEBB IIC2_1 8 2P φ/2Pφ I 2C bus status register_1 ICSR_1 8 H'FFEBC IIC2_1 8 2P φ/2Pφ Slave address register_1 SAR_1 8 H'FFEBD IIC2_1 8 2P φ/2Pφ I 2C bus transmit data register_1 ICDRT_1 8 H'FFEBE IIC2_1 8 2P φ/2Pφ I 2C bus receive data register_1 ICDRR_1 8 H'FFEBF IIC2_1 8 2P φ/2Pφ Timer control register_2 TCR_2 8 H'FFEC0 TMR_2 16 2P φ/2Pφ Timer control register_3 TCR_3 8 H'FFEC1 TMR_3 16 2P φ/2Pφ Timer control/status register_2 TCSR_2 8 H'FFEC2 TMR_2 16 2P φ/2Pφ Timer control/status register_3 TCSR_3 8 H'FFEC3 TMR_3 16 2P φ/2Pφ Time constant register A_2 TCORA_2 8 H'FFEC4 TMR_2 16 2P φ/2Pφ Time constant register A_3 TCORA_3 8 H'FFEC5 TMR_3 16 2P φ/2Pφ Time constant register B_2 TCORB_2 8 H'FFEC6 TMR_2 16 2P φ/2Pφ Time constant register B_3 TCORB_3 8 H'FFEC7 TMR_3 16 2P φ/2Pφ Timer counter_2 TCNT_2 8 H'FFEC8 TMR_2 16 2P φ/2Pφ Timer counter_3 TCNT_3 8 H'FFEC9 TMR_3 16 2P φ/2Pφ Timer counter control register_2 TCCR_2 8 H'FFECA TMR_2 16 2P φ/2Pφ Timer counter control register_3 TCCR_3 8 H'FFECB TMR_3 16 2P φ/2Pφ |
|
