Section 24 List of Registers

Rev.1.00 Jun. 07, 2006 Page 1004 of 1102

REJ09B0294-0100

Abbreviation

Number

of Bits

Address

Module

Data

Width

Access

Cycles

(Read/Write)

Port C register

PORTC

H'FFF4B

I/O port

φ/—

Port D register

PORTD

H'FFF4C

I/O port

φ/—

Port E register

PORTE

H'FFF4D

I/O port

φ/—

Port F register

PORTF

H'FFF4E

I/O port

φ/—

Port 1 data register

P1DR

H'FFF50

I/O port

φ/2Pφ

Port 2 data register

P2DR

H'FFF51

I/O port

φ/2Pφ

Port 3 data register

P3DR

H'FFF52

I/O port

φ/2Pφ

Port 6 data register

P6DR

H'FFF55

I/O port

φ/2Pφ

Port A data register

PADR

H'FFF59

I/O port

φ/2Pφ

Port B data register

PBDR

H'FFF5A

I/O port

φ/2Pφ

Port C data register

PCDR

H'FFF5B

I/O port

φ/2Pφ

Port D data register

PDDR

H'FFF5C

I/O port

φ/2Pφ

Port E data register

PEDR

H'FFF5D

I/O port

φ/2Pφ

Port F data register

PFDR

H'FFF5E

I/O port

φ/2Pφ

Serial mode register_2

SMR_2

H'FFF60

SCI_2

φ/2Pφ

Bit rate register_2

BRR_2

H'FFF61

SCI_2

φ/2Pφ

Serial control register_2

SCR_2

H'FFF62

SCI_2

φ/2Pφ

Transmit data register_2

TDR_2

H'FFF63

SCI_2

φ/2Pφ

Serial status register_2

SSR_2

H'FFF64

SCI_2

φ/2Pφ

Receive data register_2

RDR_2

H'FFF65

SCI_2

φ/2Pφ

Smart card mode register_2

SCMR_2

H'FFF66

SCI_2

φ/2Pφ

D/A data register 0

DADR0

H'FFF68

D/A

φ/2Pφ

D/A data register 1

DADR1

H'FFF69

D/A

φ/2Pφ

D/A control register 01

DACR01

H'FFF6A

D/A

φ/2Pφ

PPG output control register

PCR

H'FFF76

PPG

φ/2Pφ

PPG output mode register

PMR

H'FFF77

PPG

φ/2Pφ

Next data enable register H

NDERH

H'FFF78

PPG

φ/2Pφ

Next data enable register L

NDERL

H'FFF79

PPG

φ/2Pφ

Output data register H

PODRH

H'FFF7A

PPG

φ/2Pφ

Output data register L

PODRL

H'FFF7B

PPG

φ/2Pφ

Next data register H*

NDRH

H'FFF7C

PPG

φ/2Pφ

Next data register L*

NDRL

H'FFF7D

PPG

φ/2Pφ

Next data register H*

NDRH

H'FFF7E

PPG

φ/2Pφ

Next data register L*

NDRL

H'FFF7F

PPG

φ/2Pφ
