background image
Section 25 Electrical Characteristics
Rev.1.00 Jun. 07, 2006 Page 1074 of 1102
REJ09B0294-0100
B
φ
BACK
tBRQOD
tBRQOD
BREQO
Figure 25.34 External Bus Request Output Timing
25.3.4
DMAC Timing
Table 25.7
DMAC Timing
Conditions: V
CC = PLLVCC = DrVCC = 3.0 V to 3.6 V, AVCC = 3.0 V to 3.6 V, Vref = 3.0 V to AVCC,
V
SS = PLLVSS = DrVSS = AVSS = 0 V, Bφ = 8 MHz to 50 MHz,
T
a = –20°C to +75°C (regular specifications),
T
a = –40°C to +85°C (wide-range specifications)
Item
Symbol
Min.
Max.
Unit
Test Conditions
DREQ setup time
t
DRQS
20
ns
Figure 25.35
DREQ hold time
t
DRQH
5
ns
TEND delay time
t
TED
15
ns
Figure 25.36
DACK delay time 1
t
DACD1
15
ns
DACK delay time 2
t
DACD2
15
ns
Figures 25.37,
25.38
B
φ
DREQ0 to DREQ3
tDRQS tDRQH
Figure 25.35 DMAC (
DREQ) Input Timing
