Section 25 Electrical Characteristics
Rev.1.00 Jun. 07, 2006 Page 1075 of 1102
REJ09B0294-0100
T1
tTED
tTED
B
φ
TEND0 to TEND3
T2 or T3
Figure 25.36 DMAC (
TEND) Output Timing
T1
B
φ
A23 to A0
CS7 to CS0
AS
BS
RD/
WR
tDACD1
tDACD2
tDACD2
tDACD2
RD
(read)
D15 to D0
(read)
LHWR, LLWR
(write)
D15 to D0
(write)
T2
DACK0 to DACK3
(DKC = 0)
DACK0 to DACK3
(DKC = 1)
Figure 25.37 DMAC Single-Address Transfer Timing: Two-State Access
