H8SX/1663R Datasheet(PDF) 1108 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1108 Page - Renesas Technology Corp |
|
|
1108 / 1504 page  Section 22 A/D Converter Rev. 2.00 Sep. 24, 2008 Page 1076 of 1468 REJ09B0412-0200 Bit Bit Name Initial Value R/W Description 4 EXCKS 0 R/W Clock Extension Select Specifies the A/D conversion time in combination with the CKS1 and CKS0 bits in ADCR. Be sure to set these three bits at one time. For details, see section 22.3.5, A/D Control Register for Unit 1 (ADCR_1). 3 2 1 0 CH3 CH2 CH1 CH0 0 0 0 0 R/W R/W R/W R/W Channel Select 3 to 0 Selects analog input together with bits SCANE and SCANS in ADCR. • When SCANE = 0 and SCANS = X 00XX: Setting prohibited 0100: AN4 0101: AN5 0110: AN6 0111: AN7 1XXX: Setting prohibited • When SCANE = 1 and SCANS = 0 00XX: Setting prohibited 0100: AN4 0101: AN4 and AN5 0110: AN4 to AN6 0111: AN4 to AN7 1XXX: Setting prohibited • When SCANE = 1 and SCANS = 1 XXXX: Setting prohibited [Legend] x: Don't care Note: * Only 0 can be written to this bit, to clear the flag. |
|
