H8SX/1663R Datasheet(PDF) 1110 Page - Renesas Technology Corp |
|
|
|||||||||||||||||||||||||||||
H8SX/1663R Datasheet(HTML) 1110 Page - Renesas Technology Corp |
|
1110 / 1504 page ![]() Section 22 A/D Converter Rev. 2.00 Sep. 24, 2008 Page 1078 of 1468 REJ09B0412-0200 Bit Bit Name Initial Value R/W Description 3 2 CKS1 CKS0 0 0 R/W R/W Clock Select 1 and 0 These bits set the A/D conversion time. First select the A/D conversion time by setting bits CKS1 and CKS0 while ADST = 0 and then set the mode of A/D conversion. CKS1, and CKS0 00: A/D conversion time = 528 states* 2 (max.) 01: A/D conversion time = 268 states* 2 (max.) 10: A/D conversion time = 138 states* 2 (max.) 11: A/D conversion time = 73 states* 2 (max.) 1 0 R/W Reserved This bit is always read as 0. The write value should always be 0. [Legend] x: Don't care Notes: 1. To set A/D conversion to start by the ADTRG0 pin, the DDR bit and ICR bit for the corresponding pin should be set to 0 and 1, respectively. For details, see section 13, I/O Ports. 2. P φ criterion |
|
