2.6.1
Definition of optical characteristics
θ2
θ
θ1
Φ
X(
Φ=90°)
Y(
Φ=0°)
Y’(
Φ=180°)
Z(
Θ=0°)
Light (when reflected)
Light (when transmitted)
Detector
Bright (%)
Dark
Brightness
Brightness curve
of selected
segment
B2
B1
Operating voltage (V)
Definition of contrast Cr.
B2 = Brightness of selected segment
B1 = Brightness of not selected segment
Cr. =
X’(
Φ=270°)
